Sphera Evolution Homogeneous Vinyl
Application

Internal use, all busy commercial and public sector locations

Description

A premium collection of homogeneous vinyl flooring, offering an intricate mix of spheres, granules and colour pigments with SMART top PUR surface finish.

Features and benefits:

  • SMART top surface finish ensures that Sphera has a high resistance to chemicals, scratches and stains.
  • Evenly distributed top layer provides superior all-over protection.
  • In-line coating and subsequent embossing process for superior appearance.
  • Unique embossing process, following lacquer application, delivers durable performance.
  • Low emissions and phthalate-free manufacturing.
  • Brand new technology means that there is no back-sanding requirement, reducing the amount of raw materials used.
  • 100% of the electricity used is from a renewable source.
  • Styled by a European design team and produced in an advanced purpose-built plant, using the latest manufacturing technology.
  • An intricate mix of spheres, granules and colour pigments that delivers vibrant visuals.
  • With a palette that offers 24 colours, spanning solid, dark and light tones, Sphera Evolution is colour-coordinated to deliver contemporary integrated flooring designs.

Adhesive:

For use with 640 Eurostar Special.

Application:

Internal use, all busy commercial and public sector locations

General information

Finish

SMART top PUR surface finish

Material

Homogeneous PVC to BS EN ISO 10581

Shape

Sheet

Size

2 m width

Specification data Enhanced data

Product Reference

Sphera Evolution

Specification standard

BS EN ISO 10581 7 EN 14041

Area of use Classification - BS EN ISO 10874

Class 34 Commercial very heavy, Class 43 light industrial

Slip resistance

-

Slip resistance to UKSRG pendulum test

PTV dry: >50

(to DIN51130)

R9

Slip resistance (to EN 13893)

DS μ ≥0.30

Total thickness to ISO1765

2 mm

Roll width

2 m

Total weight (to EN ISO 23997)

2.9 kg/m²

Dimensional stability (to BS EN ISO 23999)

<0.2%

Residual indentation (to EN-ISO 24343-1)

Required ≤0.10 mm, typical ~0.03 mm

Abrasion resistance (to BS EN ISWO 660-2)

Group T

Castor chair continuous use (to ISO 4918/EN 425)

Pass

Light fastness to EN-ISO 105-B02

≥7

Flexibility (to EN-ISO 24344)

10 mm

Resistance to chemicals (to EN ISO 26987)

Very good

Bacteria resistance (to EN846)

Does not support growth

Indoor Air Emissions (to ISO 1600-6):

TVOC at 28 days: ≤10 μg/m³

Reaction to fire to EN 13501

Bfl-s1

Body voltage (to EN 1815)

<2 kV

Thermal conductivity (to EN 12667)

0.25 W/m·K

Colours

50400 aqua pearl

50401 silver white pearl

50402 sage pearl

50403 lemon pearl

50404 copper pearl

50405 bronze pearl

50430 aqua

50431 lapis

50432 silver white

50433 peakcock

50434 sage

50435 viridian

50436 lemon

50437 volcano

50438 marigold

50439 copper

50440 satin

50441 bronze

50470 shaded aqua

50471 shaded silver white

50472 shaded viridian

50473 shaded lemon

50474 shaded copper

50475 shaded bronze

Standard product features

Features:

Produced in a zero-waste environment.

Finish:

SMART top PUR surface finish.

Material:

Homogeneous PVC to BS EN ISO 10581.

Shape:

Sheet.

Size:

2 m width.

Warranty:

Ten-year guarantee.

Recycled content:

0%.

Recyclability:

100%.

Embodied carbon:

13.2 kg CO2 eq per m².

Red listed materials:

PVC.

Country of Origin:

Netherlands.

Environmental information

Embodied carbon

13.2 kg CO2 eq per m²

Recyclability

100%

Recycled content

0%

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2017 1 1.3
Download now from NBS National BIM Library
