SMARTPLY MAX FR B - Flame Retardant OSB - OSB

Verified by manufacturer 8 months ago

Square edge

MEDITE SMARTPLY Variant:
Third party certifications:
  • FSC

    FSC

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • EPD

    EPD

    Certificate type

SMARTPLY MAX FR B Flame Retardant panel is a structural, moisture resistant OSB/3 panel with outstanding and reliable reaction to fire properties.

Jump to:
BIM object icon
+44 (0)1322 424900 Website

Application

A innovative wood-based panel, it is independently certified for the most demanding structural applications in permanent constructions (wall sheathing, flooring and roofing), as well as general free-standing applications where enhanced reaction to fire performance is required, for example:


  • Timber frame construction.
  • Fire protection during construction.
  • Light Gauge Steel and modular construction systems.
  • Site security hoarding.
  • Furniture, shop fitting and general joinery.
  • Exhibition stands, film sets, stage construction.

Description

Suitable for use where strength, moisture resistance and improved flame retardance are paramount. SMARTPLY MAX FR B achieves a Reaction to Fire Classification of B-s2, d0, and Bfl-s1 (flooring) in accordance with EN13501-1. SMARTPLY MAX FR B is CE certified according to EN 13986 and meets the requirements for load-bearing panels for use in humid conditions (Type OSB/3) as defined in EN 300 and Eurocode 5.


SMARTPLY MAX FR B has been tested to:

  • EN 13823 (Single Burning Item test).
  • EN ISO 11925-2 (Single-flame Ignitability test).
  • EN ISO 9239-1 (Radiant Heat test – for flooring) and achieves a classification for construction products of B-s2, d0 and Bfl-s1 (flooring) in relation to its reaction to fire behavior in accordance with EN 13501-1:2018.


Features and benefits:

  • Reaction to fire classification (Euroclass) of B-s2, d0 and Bfl-s1 (flooring).
  • CPR Compliant – CE Marked in accordance with EN13986 at point of manufacture unlike post-treated alternatives.
  • Flame retardant treatment of wood strands during manufacture.
  • No Added Formaldehyde (NAF) or any harmful substances – contributing to healthier environments.
  • Reduces fire spread and improves fire protection during construction.
  • High racking strength – suitable for structural use OSB/3 (EN 300).
  • Light weight and easy to cut and fix compared to mineral-based panels which can crack and shatter.
  • Manufactured using FSC® certified timber from our own forests.
  • Climate Positive – more carbon is stored in the product than was emitted during manufacturing processes (A1-A3). Independently verified Environmental Product Declaration (EPD) available on request.


Find out more here: https://youtu.be/PjFZsqiMP0k

General information

Color

Other

Raw panel.

Material

Wood

Wood-based panel.

Shape

Rectangle

Length

2397 mm

Width

1197 mm

1200 mm

Uniclass

Pr_25_71_97_58 Oriented strand boardsPrimary

CAWS

K11/51 Oriented strand board sarking

K11/41 Oriented strand board roof decking

K11/39 Oriented strand board wall sheathing

K11/35 Oriented strand board flooring

K11/235 Oriented strand board floating floor

K11/435 Oriented strand board wall sheathing

K11/335 Oriented strand board flooring

K11/535 Oriented strand board roof decking

K11/635 Oriented strand board sarking

Specification data - Oriented strand boards

Standards

To EN 13823 (Single Burning Item test), EN ISO 11925-2 (Single-flame Ignitability test), EN ISO 9239-1 (Radiant Heat test – for flooring).

Grade

To BS EN 300, type OSB/3.

Reaction to fire classification

-

Flooring

To EN 13501-1, Bfl-s1.

Excluding flooring

To BS EN 13501-1, B-s2, d0.

Thickness

11 mm.

FR OSB3.

15 mm.

FR Build/ Euro C.

18 mm.

FR Build/ Euro C.

Edges

Square.

Fire-retardant treatment

Zeroignition® solution.

Size (l x w)

2397 x 1197 mm.

Colour

Raw panel.

Material:

Wood-based panel.

Sustainability data

Contains Red List materials

No

Country of material origin

Ireland

Country of product manufacture

Ireland

EPD
