Slider24 In-Line Patio Door System - Open Left
BSI Kitemark
Certificate type
Robust, high performance 2-Pane in-line sliding patio door system.
PVC-U sliding patio door.
Features and benefits:
- Robust profile construction designed to withstand extreme loads.
- Certified to the latest enhanced security standard PAS24 Secured by Design approved.
- Available in a vast array of foil colour options.
- A+ WER rating.
- Suites with Heritage 2800 window.
- Both aluminium and PVC-U interlock options available.
- Sturdy clip-fit trim fixings.
- Building Regulations Approved Document M compliant low threshold.
- Durable stainless streel track.
- Dedicated midrail for letter plate with integral screw ports for joining mechanically.
Performance:
- Air permeability (Class A4): 600 Pa.
- Water tightness: Full frame (Class E8A): 450 Pa. Low threshold (Class E5A): 200 Pa.
- Wind resistance (Class A3): 1200 Pa.
- U-value (Uw): 1.4–0.98 W/m²K. (0.98 achieved with 4/12/4/12/4 argon cavity glazing).
Features | Robust profile construction designed to withstand extreme loads, excellent weather, air and water tightness performance, wide range of colour options, aluminium and PVC-u interlock options |
Material | PVC-U |
Uniclass 2015 | |
CAWS | L20/520 Sliding doors |
Product Reference | Slider24 Patio Door |
Type | Two paneThree pane (central slider)Three pane (end slider)Four pane |
Colour/ Finish | - |
Exterior | Agate greyAnthracite greyAnthracite smoothBlack ashBlack ashChartwell greenClassic creamEnglish oakGolden oakHeritage whiteIce creamIrish oakNut treeRosewoodWhite grain |
Bead | BevelledDecorative |
Glazing | 28 mm double glazing36 mm triple glazing |
Product Options | Size (w x h):
Colour/ Finish:
- Colour Express: A unique range of foil colours in 18 colourways. - Heritage Collection: A range of premium woodgrain foils in eight colourways. |
| Platform | Compatible | Version | Certified to |
|---|---|---|---|
 IFC | IFC2X3 | 1 | 1.3 |
 Revit | Revit 2016 | 2 | 2.0 |
- PAS24
