Suspended ceiling systems.
Widely used in the construction of both residential and commercial sector buildings.
Suspended ceiling systems.
Features and benefits:
They can be used to cover a wide range of design objectives, including aesthetic, acoustics, environmental, safety and performance requirements.
Application:
Widely used in the construction of both residential and commercial sector buildings.
Features | They can be used to cover a wide range of design objectives, including aesthetic, acoustics, environmental, safety and performance requirements |
Material | Plasterboard |
Uniclass 2015 | |
CAWS | K10/220 Proprietary suspended ceiling system K10/50 Suspended ceiling on metal framing |
Product Reference | Siniat GTEC Suspended MF Ceiling Systems to Protect Structure |
Suspension grid | GTEC Ceiling Channels at 450 mm centres (maximum) |
Insulation | None or glass mineral wool (supplied by others) – Dependant on ceiling type selected, various thicknesses. |
Barriers in ceiling void | - |
Fire barriers | GTEC Intumescent Acoustic SealantPerimeter sealing to restrict smoke, sound and fire penetration. Ensures system performance. |
Acoustic barriers | GTEC Intumescent Acoustic SealantPerimeter sealing to restrict smoke, sound and fire penetration. Ensures system performance. |
Linings | - |
Inner layers | None or 12.5 mm-thick GTEC Standard Board or GTEC Fire BoardDependant on ceiling type selected. |
Face layer | 12.5 mm-thick GTEC Standard Board or GTEC Fire BoardDependant on ceiling type selected. |
Fasteners | GTEC Self-Tapping Drywall Screws |
Joint treatment | Insert requirements from manufacturer's literature. |
System accessories | NoneGTEC Connecting ClipsFor RCC 016 and RCC 018 only. |
Type | RCC 016: Suspended MFSystem weight: 11 kg/m². RCC 017: Suspended MFSystem weight: 22 kg/m²; Fire performance: 30 minutes. RCC 018: Suspended MFSystem weight: 13 kg/m²; Fire performance: 30 minutes. RCC 019: Suspended MFSystem weight: 26 kg/m²; Fire performance: To BS 476-23: 60 minutes; to BS EN 1364-2: 30 minutes. |
Sealer | GTEC Drywall SealerIvory, pre-decoration coat for plasterboard. GTEC Universal SealerFor use on plasterboard prior to painting for improved whiteness and covering power. |
Structure | Any suitable soffit |
Standard product features | Features: They can be used to cover a wide range of design objectives, including aesthetic, acoustics, environmental, safety and performance requirements. Material: Plasterboard. |
