Shower Seats

Description

A range of shower seats.

Features and benefits:

  • Construction consisting of a wall bracket and continuous seat (Doc M: Backrest to be mounted separately).
  • Slip-resistant, textured seat made of synthetic material in HEWI colours 98 (signal white) and 92 (anthracite grey).
  • Reinforcement of the seat made of aluminium, powder-coated in the colour of the seat.
  • Wall bracket made of stainless steel/ metal.
  • The seat can be folded up to save space.
  • The aluminium seat bracket ensures stability and safety.
  • The moulded seat of the hinged seat defines the sitting position (lightly curved shape provides suitable support).
  • Seat manufactured from thermoplastic synthetic material (polypropylene) enables and extremely resistant, hygienic surface and particularly soft seat comfort.
  • Maintenance-free, permanently smooth and easy moving joint.
  • Tool-free and quick installation.
  • Secured by fixing screw.
  • For mounting with non-corrosive and tested HEWI fixing materials for different wall systems (to be ordered separately).
  • Sealing tape for sealing the fixing points is included in the scope of supply.
  • Fulfils the highest cleaning product resistance and hygiene requirements.

Approvals:

  • Doc 'M' seats meet the requirements of British Standard BS 8300: 2009 + A1: 2010/ Doc M.
  • Non-Doc 'M' seats meet the requirements of DIN 18040, Önorm B1600/1601 and SIA 500.

General information

Uniclass 2015

Pr_40_20_06_83 Shower seatsPrimary

CAWS

N13/448 Seats

Specification data - Shower seats

Product Reference

Shower Seat

Type

See 'Options' below and insert reference.

Standard product features

Size (h x d):

Varies, depending on product type. Consult literature for details

Weight capacity:

150 kg (maximum).

Product Options

Type:Type:

- Chrome:

  • Shower Seat 450 mm (Fixed) Chrome/ Anthracite grey Bracket – 900.51.20240 92.
  • Shower Seat 450 mm (Fixed) Chrome/ Signal white Bracket – 900.51.20240 98.
  • Shower Seat 450 mm (Fixed) Doc 'M' Chrome/ Anthracite grey Bracket – 900.51.20340 92.
  • Shower Seat 450 mm (Fixed) Doc 'M' Chrome/ Signal white Bracket – 900.51.20340 98.
  • Shower Seat 450 mm (Mobile) Chrome/ Anthracite grey Bracket – 900.51.40140 92.
  • Shower Seat 450 mm (Mobile) Chrome/ Signal white Bracket – 900.51.40140 98.

- Matt coated:

  • Shower Seat 450 mm (Fixed) Doc 'M' Matt Bracket – 900.51.20360 CD.
  • Shower Seat 450 mm (Fixed) Doc 'M' Matt Bracket, Light grey pearl mica/ white – 900.51.20360 AX.
  • Shower Seat 450 mm (Fixed) Doc 'M' Matt, Black/ black Bracket – 900.51.20360 CV.
  • Shower Seat 450 mm (Fixed) Doc 'M' Matt, White/ white Bracket – 900.51.20360 AS.
  • Shower Seat 450 mm (Fixed) Matt Bracket, Dark grey pearl mica/ white – 900.51.20260 CD.
  • Shower Seat 450 mm (Fixed) Matt Bracket, Light grey pearl mica/ white – 900.51.20260 AX.
  • Shower Seat 450 mm (Fixed) Matt, Black/ black Bracket – 900.51.20260 CV.
  • Shower Seat 450 mm (Fixed) Matt, White/ white Bracket – 900.51.20260 AS.
  • Shower Seat 450 mm (Hanging) Doc 'M' Compliant Matt, Black/ black – 900.51.11260 CV.
  • Shower Seat 450 mm (Hanging) Doc 'M' Compliant Matt, Dark grey pearl mica/ white – 900.51.11260 CD.
  • Shower Seat 450 mm (Hanging) Doc 'M' Compliant Matt, Light grey pearl mica/ white – 900.51.11260 AX.
  • Shower Seat 450 mm (Hanging) Doc 'M' Compliant Matt, White/ white – 900.51.11260 AS.
  • Shower Seat 450 mm (Mobile) Matt, Black/ black Bracket – 900.51.40160 CV.
  • Shower Seat 450 mm (Mobile) Matt, Dark grey pearl mica/ white Bracket – 900.51.40160 CD.
  • Shower Seat 450 mm (Mobile) Matt, Light grey pearl mica/ white Bracket – 900.51.40160 AX.
  • Shower Seat 450 mm (Mobile) Matt, White/ white Bracket – 900.51.40160 AS.

- Satin stainless steel:

  • Shower Seat 450 mm (Fixed) Doc 'M' Satin Stainless Steel/ Anthracite grey Bracket – 900.51.203XA 92.
  • Shower Seat 450 mm (Fixed) Satin Stainless Steel/ Anthracite grey Bracket – 900.51.202XA 92.
  • Shower Seat 450 mm (Fixed) Satin Stainless Steel/ Signal white Bracket – 900.51.202XA 98.
  • Shower Seat 450 mm (Mobile) Satin Stainless Steel/ Anthracite grey Bracket – 900.51.401XA 92.
  • Shower Seat 450 mm (Mobile) Satin Stainless Steel/ Signal white Bracket – 900.51.401XA 98.
  • Shower Seat 450 mm (Fixed) Doc 'M' Satin Stainless Steel/ Signal white Bracket – 900.51.203XA 98.
