ShieldFLEX R Mastic Asphalt Waterproofing System

Verified by manufacturer over a year ago

Shield Membranes Ltd Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

Asphalt waterproofing system.

Jump to:
+44 (0)20 77409279 Website

Application

Can be used on horizontal, sloped and vertical surfaces. The system is for use externally and in sandwich constructions for waterproofing and above and below ground damp-proof applications and has been designed, tested and certified as being durable enough to exceed the design life of any structure in which it may be installed.

Description

ShieldFLEX R waterproofing system is a polymer modified roofing grade of mastic asphalt, specifically designed for flat roofs and podiums and has been designed, tested and certified as being durable enough to exceed the design life of any roof in which it may be installed while achieving a fire rating of Broof(t4). The polymer modification allows the product to retain its integrity at lower temperatures, and on areas with more movement than that which conventional roofing grades of Mastic asphalt could withstand. When installed correctly, ShieldFLEX R is an extremely durable waterproofing system and allows for far greater traffic and usage than other waterproofing systems. A variant with an unbroken terrazzo finish is available for internal use.


Technical characteristics:

  • Specific gravity: 2.0 - 2.4.
  • Water vapour permeability: 0.067% (g/day).
  • Flash point: >300°C.


Features and benefits:

  • BBA Certified.
  • Proven track record.
  • Unapparelled durability for the application.
  • Polymer modified to increase durability and extend life expectancy
  • Expected life exceeds that of any structure
  • Broof(t4) reaction to fire.
  • ≥15 mm laying thickness (in 5 mm increments).

General information

Color

Black

Red

Finish

Float

Polished

Material

Mastic asphalt

Warranty description

40 year

Manufacturer guidance

Up to 40 years.

Uniclass

Pr_35_31_05_72 Roofing, tanking and flooring mastic asphalt (MA)Primary

CAWS

J21/26 Mastic asphalt

J21/402 Mastic asphalt (roofing)

Specification data - Roofing, tanking and flooring mastic asphalt (MA)

Third party certification

BBA Certified - 17/5459.

Colour

Black.

Density

2100–2150 kg/m³.

Curing time

Light foot traffic: 30–50 minutes; full traffic: 24 hours.

Sustainability data

Country of product manufacture

United Kingdom

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

5 %

Guidance for specification option:

Up to.

Third party certifications

BBA Agrément Certificate

17/5459 ShieldFLEX R Roof Waterproofing System

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001 Quality Management System

ISO 14001 Environmental Management Systems

ISO 14001 Environmental Management Systems

ISO 14001 Environmental Management System
