Shaped Box Gutters - Guttering System
Verified by manufacturer 28 days ago
Aluminium shaped box gutters available in various sizes with multiple outlet options and finishes, suitable for diverse architectural needs.
Application
Used as an alternative to traditional box gutters in building rainwater management systems, suitable for various architectural styles and building types requiring custom-sized guttering solutions.
Description
Shaped Box Gutters are an alternative to box gutters, available in a wide range of sizes and can be manufactured as required.
Features and benefits:
Features and benefits:
- Available in standard gutter lengths of three metres and one and a half metres.
- Material thickness is 2 mm across all sizes.
- Multiple gutter sizes ranging from 100 x 75 mm up to 300 x 200 mm.
- Includes various outlet sizes and types such as round and square/rectangular outlets.
- Offers a variety of angles including 90° external and internal, 135° external and internal, and irregular angles.
- Stop ends are provided as internal stop ends with right hand and left hand options.
- Manufactured from aluminium material.
- Available in mill finish and PPC (polyester powder coated) finish options.
- Compatible with a range of gutter brackets including side rafter, top rafter, and mortar brackets.
General information
Color | Red Silver Other |
Finish | Powder-coated Mill |
Material | Aluminium |
Shape | Rectangle Other |
Length | 3000 mm 1500 mm |
Width | 100 mm 125 mm 150 mm 200 mm 300 mm |
Height | 75 mm 100 mm 150 mm 200 mm |
Uniclass | |
CAWS | R10/11 Aluminium gutters R10/311 Aluminium gutters |
SKU Code | SBX1/1,SBX2/1,SBX3/1,SBX4/1,SBX5/1,SBX6/1,SBX7/1,SBX8/1,SBX1/2,SBX2/2,SBX3/2,SBX4/2,SBX5/2,SBX6/2,SBX7/2,SBX8/2,SBX1/10,SBX2/10,SBX3/10,SBX4/10,SBX5/10,SBX6/10,SBX7/10,SBX8/10,SBX1/11,SBX2/11,SBX3/11, |
Sustainability data
Material | Aluminium |
Literature
Literature type
Gutters Shaped Box Brochure
Shaped box gutter system DS
