Shadmaster Fire Door FD30, FD60 - Fire doors

Verified by manufacturer 2 months ago

FD30/ E30

Shadbolt International Variant:

Solid core flush door.

Jump to:
+44 (0)1376 333376 Website

Application

Suitable for larger structural opening sizes that require 60 minute fire rating.

Description

Shadmaster doors have a laminboard core construction and may be used where exceptionally large sizes or greater fire resistance (up to 60 minutes) are required.

The doors offer a surface for veneering and good mechanical and acoustic performance.


Features and benefits:

  • Door leaf accuracy adheres to BS 5277 and 5278: maximum permitted deviations in flatness and squareness are less than half those permitted by BS 5277 and 5278 (up to 60 minutes performance).
  • Door leaves can be supplied in extended sizes, including storey height, without compromising performance.
  • The standard Shadmaster construction combines high performance for fire resistance, sound insulation and mechanical properties (up to 60 minutes performance).
  • Door leaves of co-ordinated appearance can be used throughout a scheme, irrespective of performance for individual doors.
  • Glazed apertures can be included without compromising performance.
  • Can be supplied as doorsets complete with frames, seals and ironmongery, glazing where required, with validated fire performance, and generally fully finished.


General information

Finish

Matt

Guidance for specification option:

Frame and door leaf facing.

Satin

Guidance for specification option:

Frame.

Gloss

Guidance for specification option:

Frame.

Stained

Guidance for specification option:

Frame.

Material

Laminate

Guidance for specification option:

Plastic laminate.

Wood

Guidance for specification option:

Wood veneer.

Glass

Shape

Rectangle

Length

Bespoke

Guidance for specification option:

Maximum size.

Width

Bespoke

Guidance for specification option:

Maximum size.

Height

Bespoke

Warranty description

One year

Uniclass

Pr_30_59_23_97 Wood flush door leavesPrimary

CAWS

L20/20 Wood flush doors

L20/230 Wood flush doors

Product range

Non Fire Rated and Fire Rated Doors and Doorsets

Specification data - Wood flush door leaves

Thickness

44 mm.

54 mm.

Door leaf size

As drawing.

As schedule.

Manufacturer guidance

Maximum 1500 x 3000 mm.

Performance

-

Fire resistance

-

Integrity

To BS 476-22 and BS EN 1634-1, 30 minutes.

Acoustic performance

Not applicable.

Strength and durability

To BS EN 1191, 1192 and 12400, Class 4.

Guidance for specification option:

Heavy duty (up to 60 minutes).

Manufacturer guidance

Mechanical performance.

Door structure

Solid core.

Guidance for specification option:

Solid timber comprising narrow laminated spruce sections.

Facings

Plastic laminate, colour.

Guidance for specification option:

Alternative facings.

Insert requirements.


Wood veneer, species.

Guidance for specification option:

Available in wide ranges.

Insert requirements.

Paint lacquer.

Guidance for specification option:

Alternative facings.

Manufacturer guidance

Consult with manufacturer for exact details and product references.

Lippings

Lip two vertical edges concealed.

Lip two vertical edges exposed.

Lip four edges concealed.

Lip four edges exposed.

Manufacturer guidance

Minimum 7 mm thickness in near matching hardwood, applied using radio-frequency glue without tongue to the two long edges or all four edges.

Hardware

As schedule.

Guidance for specification option:

Insert requirements.

Finish

Semi-matt lacquer.

Guidance for specification option:

For wood veneer facings.

Two coats of high-solid acid-catalysed semi-matt (20% gloss).

Semi-matt polyurethane lacquer.

Guidance for specification option:

For wood veneer facings.

Two coats of high-solid acid-catalysed semi-matt (20% gloss).

Semi-matt UV cured lacquer.

Guidance for specification option:

For wood veneer facings.

Two coats of high-solid acid-catalysed semi-matt (20% gloss).

Coloured plastic laminate.

Guidance for specification option:

For plastic laminate finish.

Consult with manufacturer for exact details and product references.

Coloured paint lacquer.

Guidance for specification option:

Consult with manufacturer for exact details and product references.

Manufacturer guidance

Finish as delivered.


Glazed aperture

Not required.

As drawing.

Guidance for specification option:

Insert requirements.

FD30 clear glass 7.2 mm.

Rounded vertical edges

Not required.

Required.

Manufacturer guidance

Frame rounded vertical edges.

Sub frame

18 mm MDF/ softwood assembled and braced.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0.72 kg CO₂ eq/m³
