SGG Emalit Evolution
Application

  • External facade cladding.
  • Internal cladding; exceptionally resistant to humidity - often used to clad laboratories, where hygiene and durability are important.
  • Can be placed with insulated spandrel panels.

Description

An opaque coloured glass, produced by uniformly enamelling one side of the glass. The product is exceptionally durable, as the enamel is fired at very high temperatures, fusing permanently with the glass surface.

Advantages:

  • More environmentally friendly; the enamel is free from lead and is totally recyclable.
  • Coloured facades; available in a wide range of colours.
  • Exceptional durability and safety.
  • Simple installation.

Applications:

  • External facade cladding.
  • Internal cladding; exceptionally resistant to humidity - often used to clad laboratories, where hygiene and durability are important.
  • Can be placed with insulated spandrel panels.

Standards:

SGG Emalit Evolution is a toughened safety glass conforming to BS EN 12150. It can also be heat-strengthened, in accordance with BS EN 1863.

General information
Uniclass 2015
Pr_25_71_33_37 Heat-strengthened glass sheetsPrimary
CAWS

L40/310 Bead-fixed single-glazing

L40/330 Bead-fixed single-glazing

L40/55 Bead-fixed insulating glass units

L40/381 Bead-fixed insulating glass units

L40/350 Bead-fixed single-glazing

L40/250 Bead-fixed single-glazing

L40/210 Putty-fronted single-glazing

L40/230 Bead-fixed single-glazing

L40/370 Bead-fixed insulating glass units

L40/430 Single-glazing into grooves

L40/470 Zipper gasket glazing

H11/110 Curtain walling

L40/371 Bead-fixed insulating glass units

H13/115 Structural glass assembly

L40/260 Bead-fixed single-glazing

L40/40 Putty-fronted single-glazing

L40/530 Internal tape glazing

H10/10 Patent glazing

L40/90 Internal tape glazing

L40/50 Bead-fixed single-glazing

L40/57 Bead-fixed insulating glass units

L40/490 Single-sided gasket glazing

L40/450 Single-glazing into grooves

L40/58 Bead-fixed insulating glass units

L40/410 Single-glazing into grooves

H10/115 Patent glazing

L40/372 Bead-fixed insulating glass units

L40/380 Bead-fixed insulating glass units

Specification data - Heat-strengthened glass sheets
Product Reference

SGG Emalit Evolution

Type

SGG Emalit Evolution

SGG Emalit Metall

Special pigmented enamel gives a metallic effect.

Thickness

6 mm

8 mm

10 mm

Insulation

Not required

CFC-free foam

Mineral fibre

Processing

Not required

Curved

Double glazed

Laminated

Product Options

Size (w x h):

Available 300–2080 x 500–3600 mm.

Colour:

Sunrise Yellow, Zest Yellow, Summer Yellow, Blue Tone, Regal Blue, Electric Blue, Ocean Blue, Leaf Green, Lime Green, Jade Green, Cactus Green, Graphite Grey, Dark Grey, Mid Grey, Industrial Grey, Neutral Grey, Harmonic Bronze, Weathered Bronze, Black and Polar White colours are available, with bespoke colours and colour-matching services available on request.

Insulation:

Insulation can be added to both single and double-glazed spandrel panels to improve thermal performance.
