Security Pass Door

Security Pass Door

Safetell Ltd

Safetell’s Pass Doors offer a high security solution designed to assist entry and exit in conjunction with our Security Portals and Revolving Doors.

Jump to:
+44 (0)1322 223233 www.safetell.co.uk
Application

Suitable areas of application include:

  • Airports.
  • Banks.
  • Embassies.
  • Corporate buildings.
  • Prisons.
  • Data centres.
  • Ministries.
  • Jewellers.
  • Leisure centres.
  • Secure areas.

Description

Safetell’s Pass Doors offer a high security solution designed to assist entry and exit in conjunction with our Security Portals and Revolving Doors. They are available as emergency exit doors with a panic hardware, in a range of passage widths, including a DDA approved wide version.We provide a range of security resistance levels including EN1627 RC4 Manual Attack rating and EN1522 FB3 Ballistic Rating. Our Pass Doors are designed to be integrated with any access control system. Typical applications include corporate buildings, data centres, leisure centres and areas where Security Portals and Revolving Doors are utilised.

Features and benefits:

  • Fully Glazed or Solid Door Options
  • DDA Wide Version Available
  • Up to RC4 anti-burglary according to EN 1627 / P7B according to EN 356
  • Up to FB3 bullet resistant according to EN 1522/ BR3/S bullet resistant according to EN 1063
  • Escape routes CE certification according to EN 14351-1
  • 3 point locking system with automatic locking
  • Anti-panic Push Bar according to EN1125
  • Electromagnetic Locking with holding force up to 650 Kg
  • Finished in a number of PPC RAL colours.

Application:

Suitable areas of application include:

  • Airports.
  • Banks.
  • Embassies.
  • Corporate buildings.
  • Prisons.
  • Data centres.
  • Ministries.
  • Jewellers.
  • Leisure centres.
  • Secure areas.

General information

Uniclass 2015

Pr_30_59_24_80 Sliding door and partition setsPrimary

CAWS

L20/490 Automatic doors

Specification data - Sliding door and partition sets

Product Reference

Security Pass Door

Height

2190mm (Passage 2100)

Width

1225 mm

1525 mm

Resistance Levels

EN1627

RC4 Manual Attack rating and EN1522 FB3 Ballistic Rating
