SeceuroGlide Excel
Application

Suitable for garage door applications.

Description

Remote control, insulated roller garage door, tested and approved to police and insurance standards. Certified to the Loss Prevention Certification Board’s LPS 1175: Issue 5 burglary resistance standard and awarded ‘Secured by Design’ status by ACPO Crime Prevention Initiatives Ltd. In addition, SeceuroGlide Excel is fully CE-compliant and safety-tested.

Application:

Suitable for garage door applications.

General information

Size

As drawing

Insert reference.

As schedule

Insert reference.

Uniclass 2015

Pr_30_59_84_73 Roller shuttersPrimary
Specification data - Roller shutters

Product Reference

SeceuroGlide Excel

Size

As drawing

Insert reference.

As schedule

Insert reference.

Colour

Insert requirement from 'Options' below.

Guide rails colour

Anthracite

Light grey

Metallic silver

Yellow

Special order

Insert colour requirement; can be colour-matched.

Shutter box

-

Type

Not required

Required

Shutter box colour

Brown

White

Special order

Insert colour requirement.

Standard product features

Required headroom:

  • Doors up to 2500 mm opening height: 300 mm.
  • Doors up to 3500 mm opening height: 350 mm.

Slats:

  • CD77 twin-walled aluminium slat, insulated with CFC-free foam to reduce heat loss and sound transmission.
  • Nominal size: 78.5 mm high, 17 mm thick.
  • Assembly: slats are held in place with high-performance nylon webbing. For additional strength, SeceuroGlide features a 77 mm extruded aluminium bottom slat which incorporates a 25 mm rubber seal to help prevent water ingress and draughts.

Axle assembly:

  • Construction: 100 mm galvanized steel fluted axle. A locking collar and bolt are incorporated into the axle. As SeceuroGlide closes, the bolt engages with the endplate’s lock comb to secure the door.
  • Motor: Somfy tubular motor.
  • End plates: 3 mm galvanized steel. Designed to fit into the top of the guide rail for easy location during installation. Features integral comb lock for security mechanism.

Guide rails:

  • Construction: extruded aluminium with dense brush strip insert for improved insulation.
  • Size: 90 x 34 mm (w x d).

Control:

  • Remote unit: SeceuroSmart remote receiver unit with integral courtesy light and two-key fob transmitters with rolling code technology.
  • Safety: all SeceuroSmart receiver units supplied with a bottom slat, safety edge, pressure-sensitive device as standard.

Additional security features:

  • Bottom slat anchor: a patented steel anchor device attached to the extruded bottom slat fits into a special receptacle within the guide rail to prevent the curtain from being forced out of its guides.
  • Reinforcing guide rail feet: on doors where the guide rails are fitted within the reveal, SeceuroGlide Excel guide rails feature reinforcing steel shoes to secure them to the floor.

Installation:

Internally face-fixed.

Product Options

Size:

Available up to 5200 x 3500 mm (w x h). At 3500 mm height, the maximum width is restricted to 3000 mm.

Slat colour:

  • Standard colours: White, Burgundy, Navy Blue, Light Beige, Brown, Fir Green, Yellow, Medium Oak, Light Grey, Metallic Silver, Anthracite, Black.
  • Textured woodgrain surcharge colours: Rosewood, Mahogany, Golden Oak.
