SeceuroFire 30, 60, 120, 240

Third party certifications:

QA Certificate
Certificate type

Electrically operated, automatic, vertical fire-resistant shutter.

Jump to:

Application

For use as a standard shutter within openings e.g. in shopping centres, until required for automatic deployment.

Description

Electrically operated, automatic, vertical fire-resistant shutter, available in four different integrity ratings.

Designed to be a security barrier during normal use, and to be closed automatically during a test or emergency situation. In the event of receiving a fire alarm signal, the barrier will perform a powered descent to create a fire resistant barrier. In the event of power failure, the shutter will close using the battery back-up feature.

Features and benefits:

Suitable for both face or reveal installations.

Provides easy access to the end plate fixtures, with easy and quick attachment.

Wide variety of sizes available.

Fast and easy attachment of the axle, with two shelf brackets and easy access bolts.

Non-welded assembly design allows post order alteration if required.

Range of hood configurations available.

Fixing kits are available if required - consult manufacturer for details.

Guide offsets are symmetrical.

Can be RAL or BS coated.

Manufactured in the UK.

Tested to EN 16034: 2014, and approved by Warrington Fire.

12-month guarantee.

Consult manufacturer for details of maintenance recommendations.

Application:

For use as a standard shutter within openings e.g. in shopping centres, until required for automatic deployment.

General information

Finish

Galvanized

Standard.

Powder-coated

Insert RAL or BS colour requirement.

Uniclass 2015

Pr_30_59_84_30 Fire-resisting roller shuttersPrimary

L20/610 Roller shutters/ curtains

Specification data - Fire-resisting roller shutters

Product Reference	Seceurofire 30 30 minutes integrity performance. Seceurofire 60 60 minutes integrity performance. Seceurofire 120 120 minutes integrity performance. Seceurofire 240 240 minutes integrity performance.
Opening sizes	660–5500 x 660–5500 mm (w x h), insert requirements.
Arrangement	Face fitted Reveal fixed
Shutter curtain	75 mm scrolled slats
Control	FC Control Panel Includes alarm input, emergency override, audio visual output and 24 V battery back-up. FC+ Control Pane As FC, with split drop curtain and safety device inputs. SFP Control Panel and Key Switch With Power Manager battery back-up and interface internally fitted for NRG panel. SFP+ Control Panel and Key Switch As SFP, with additional override functionality. SF1 Control Panel and Key Switch With Power Manager battery back-up and interface internally fitted for panel. ProMate and Key Switch With Power Manager battery back-up.
Finish	Galvanized Standard. Powder-coated Insert RAL or BS colour requirement.
Accessories/ Other requirements	Not required Audio visual warning device Only available for use with control panel. Emergency retract switch FS control repeater panel Only available for use with control panel. Key switch Only available for use with control panel. Photocell Only available for use with control panel. Smoke detector Only available for use with control panel. Stop button Only available for use with control panel.

Standard product features

Components:

Box assembly: Galvanized steel sleeved sections (to allow for expansion starting from 250 mm endplate, depending on shutter height and component integrity requirements).
