SeceuroDoor 77
Application

Suitable for commercial and industrial applications. This product can be installed internally or externally.

Description

Industrial-style steel roller shutter with foam-filled slat profile. Minimal thermal bridges and the use of fine-pored polyurethane (PU) rigid foam infill ensure good thermal insulation, whilst curtain and sealing technology used around the entire shutter reduces noise from both inside and outside.

Features and benefits:

  • Heat transmission performance for the 77 mm single-slat profile 4.01 W/(m²·K).
  • A choice of motor available.
  • Can be powder-coated in any colour.
  • Choice of four guide arrangement options.
  • Standard guide angle is 75 x 50 mm (other sizes are available on request).
  • Safety edge included.

Application:

Suitable for commercial and industrial applications. This product can be installed internally or externally.

General information
Finish

Galvanized

Standard.

Mill

Guide channels.

Powder coated

Insert requirements.

Uniclass 2015
Pr_30_59_84_73 Roller shuttersPrimary
CAWS

L20/610 Roller shutters/ curtains

Specification data - Roller shutters
Product Reference

SeceuroDoor 77

Finish

Galvanized

Standard.

Mill

Guide channels.

Powder coated

Insert requirements.

Motor

Consult manufacturer for details and insert requirements.

Accessories

None

Bullet lock

Standard product features

Size (h x w, minimum–maximum):

1000–5000 x 1000–6000 mm. Maximum area: 20 m².

- Laths:

Nominally 77 mm high x 15 mm thick.

- Bottom slat (h x d):

77 x 17 mm.

- Hood and fascia:

To suit end plate (350–550 mm).

- Guide channels (w x d):

69 x 32 mm.

Construction:

- Laths:

Foam-filled, insulated lath.

- Bottom slats:

Extruded bottom slat.

- Hood and fascia:

Two or three-piece steel casing with steel end plates.

- Guide channels:

3 mm galvanized steel channels.

Operation:

- Electric:

Electric operation is by a single or three-phase motor, either direct-drive or chain-driven. Control is by either a control panel or a momentary switch, which must be held until the shutter reaches the desired position.

Weight:

12 kg/m².

Fixings:

Varies depending on the application; consult the literature for details. The hood is fixed at each end and 1000 mm centres.
