SECCO Sistemi - Windows, Doors
Verified by manufacturer 27 days ago
SECCO - EBE 85 - door inward opening
SECCO - EBE 85 - door inward opening
Range of glazing products, featuring doors and windows.
Application
Suitable for door and window openings.
Description
Integrated systems for windows and doors.
- ØG - passive magnetic levitation system.
- EBE - sculptural, solid and suitable for large spans.
- OS2 - elegant and minimal.
Features and benefits:
- Natural surfaces.
- Interpret the trends of contemporary architecture.
- Manufactured from precious, solid and durable materials.
General information
Color | Clear Other |
Finish | Glazed Galvanized |
Material | Glass Brass Steel Stainless steel Cor-Ten |
Shape | Rectangle Square Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | L20/55 Doorsets L20/480 Doorsets L10/20 Steel windows L10/310 Steel windows L10/560 Glazed screen system |
Specification data - Partition panels
Unit size | |
Thickness | Manufacturer's standard. |
Partition height (nominal) | Manufacturer guidanceConsult manufacturer for options and insert requirements. |
Width (nominal) | Manufacturer guidanceConsult manufacturer for options and insert requirements. |
Panel partition type | Glazed. |
Framing, fixing points and joints | Thermally broken, stainless steel framing profile.Guidance for specification option: Consult manufacturer for details. |
Glazed panels | |
Type | Double-glazed.Triple-glazed. |
Door arrangement | |
Type | Doorset system. |
Door frames | Steel. |
Hardware | Manufacturer guidanceConsult manufacturer for details and insert requirements. |
Seals | Manufacturer guidanceConsult manufacturer for details and insert requirements. |
Frame colour/ finish | Manufacturer guidanceConsult manufacturer for details and insert requirements. |
Air permeability | To EN 12207, 4. |
Watertightness | To EN 12208, 4A. |
Resistance to wind load | To EN 12210, C3. |
Light Transmittance (Tv) | To EN 12567-1, 1.12 W/m²K. |
Security | To EN 1627, RC 3 (burglar resistance). |
Acoustic performance | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Italy |
Country of product manufacture | Italy |
Material | Glass Brass Steel Stainless steel Cor-Ten |
