OS2 65 doorset
Slimline heritage doors offering vintage appeal with modern thermal, acoustic and security performance.
Residential doors for a wide range of applications such as:
Slimline heritage doors offering vintage appeal with modern thermal, acoustic and security performance.
Features and benefits:
Color | Silver Brown Grey Clear Other |
Finish | Galvanized Weathered Polished Burnished Glazed |
Material | Steel Stainless steel Brass Cor-Ten Carbon steel |
Shape | Rectangle Square Other |
Length | 65 mm 75 mm 85 mm Manufacturer guidanceProfile depth. |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | L20/480 Doorsets L20/55 Doorsets |
Classification data | |
Doorset | |
Type | Metal doorset. |
Fasteners | Guidance for specification option: Consult manufacturer for options and insert requirements to suit substrate. |
Glazing | Guidance for specification option: Consult manufacturer and insert requirements, 24–35 mm thick. |
Seals or inserts | |
Frame | Internal and external gaskets plus central flipper gasket. |
Classification and certification labelling | |
Format | Manufacturer’s standard. |
Thresholds | |
Base | Flush threshold. Low threshold. Not required. Manufacturer guidanceStructural thermal break profile - two metal shells (cold profiled) joined together by extruded polyamide and made integral to the parts by polyurethane resin. |
Over panels | Guidance for specification option: Consult manufacturer for options and insert requirements, or omit. Manufacturer guidanceInclude drawing and/ or schedule reference as required. See also Configuration below for door arrangement. |
Side panels | Guidance for specification option: Consult manufacturer for options and insert requirements, or omit. Manufacturer guidanceInclude drawing and/ or schedule reference as required. See also Configuration below for door arrangement. |
Hardware | Guidance for specification option: Consult manufacturer for options and insert requirements. They are available in the same range of finishes as the profiles to ensure design continuity. |
System accessories | Guidance for specification option: Consult manufacturer for options and insert requirements, or omit. |
Size | Guidance for specification option: Consult manufacturer for options and insert requirements. Shapes: Square, rectangular, Curved head, Gothic Arch, Curved on plan, Raked Head. Manufacturer guidanceInclude drawing and/ or schedule reference as required. |
Configuration | Guidance for specification option: Consult manufacturer for options and insert requirements. Manufacturer guidanceInclude drawing and/ or schedule reference as required. Maximum visible frame width of 62 mm (external - central node(s); lateral nodes are 47 or 27 mm); dimensions depend on configuration required; consult manufacturer for details. |
Colour/ Finish | Satin Brass. Patinated Brass (Architectural Bronze). Corten. Stainless Steel. Burnished Stainless Steel (darkened Stainless Steel). Painted galvanized steel - Black RAL 9005 Matt. Painted galvanized steel - Black RAL 9005 Semi-gloss. Painted galvanized steel - Graphite Grey RAL 7024 Matt. Painted galvanized steel - Graphite Grey RAL 7024 Semi-gloss. Painted galvanized steel - Anthracite Grey RAL 7016 Matt. Painted galvanized steel - Anthracite Grey RAL 7016 Semi-gloss. Painted galvanized steel - Cream White RAL 9001. Painted galvanized steel - Traffic White RAL 9016. Painted galvanized steel - Pure White RAL 9010. Painted galvanized steel - RAL colour. Guidance for specification option: Consult manufacturer and insert colour requirements. Specialist colours available on request. |
FrameMaterial | As Colour. |
Door leaf | Maximum 65 mm thick. Guidance for specification option: Maximum depth. |
Beading | Squared. Triangular. Thin. Gothic. Bevelled. Recessed. |
Opening | Inward. Outward. |
Security | RC 2. |
Air permeability | To EN 12207, Class 3. Manufacturer guidanceMaximum certified performance. |
Watertightness | To EN 12208, Class 1A. Manufacturer guidanceMaximum certified performance. |
Resistance to wind load | To EN 12210, Class C1. Manufacturer guidanceMaximum certified performance. |
Whole window U-value | U-value: 1.35 W/m²K. Manufacturer guidanceMaximum certified performance. |
Acoustic performance | 43 dB. Guidance for specification option: Consult manufacturer for further details. |
Material | Steel Stainless steel Brass Cor-Ten Carbon steel |
