NBS Source
SatinDeco LamiGlass Colour - Lami Bronze 3628

Application

  • Partitions.
  • Windows and facades.
  • Furniture.
  • Balustrade.
  • Floors and stairs.
  • Shower enclosures.
  • Roof lights.
  • Conservatory roofs.
  • Countless interior design options.

Description

SatinDeco is an acid etched glass with a silky, translucent finish. It may also be supplied laminated or as an opaque product with mirror backing. The automated manufacturing process creates a perfectly uniform finish which is highly resistant to stains and fingerprints. It is used in both residential and commercial buildings for privacy or uniform diffused light in exterior facades, partitions, staircases, doors and furniture, also in kitchens, toilet areas and bathrooms.

Further processing:

  • Cut to size.
  • Toughening.
  • Heat soaking.
  • Heat strengthening.
  • Laminating.
  • Drilling.
  • Notching.
  • Bending.
  • Edgeworking.
  • Brilliant cutting.
  • CNC shaping.
  • Manufacture into suitable single, double or triple glass insulating units.

Benefits:

  • Privacy.
  • Uniform light transmission.
  • Greater resistance to marks and stains.
  • Helps characterise interior design.
  • Sophisticated appearance.
  • Modern alternative to pattern glass.
  • Can be combined with LamiGlass for safety.
  • Can be combined with Mirror to produce a silky, reflective finish.

Applications:

  • Partitions.
  • Windows and facades.
  • Furniture.
  • Balustrade.
  • Floors and stairs.
  • Shower enclosures.
  • Roof lights.
  • Conservatory roofs.
  • Countless interior design options.

Standards:

Guardian Europe has ISO 9001 accreditation for the manufacture of float glass at all of its European based float glass plants. Guardian float glass complies with the requirements of EN 572-2: 1994 'Glass in Building - Basic soda lime silicate glass products -2: Float glass'.

General information

Features

Break safe characteristics, colourful interior and exterior design, combines privacy with safety and decorative colour

Uniclass 2015

Pr_25_71_33_88 Thermally toughened glass sheetsPrimary

CAWS

H10/10 Patent glazing

H10/115 Patent glazing

H11/110 Curtain walling

H13/115 Structural glass assembly

L40/210 Putty-fronted single-glazing

L40/230 Bead-fixed single-glazing

L40/250 Bead-fixed single-glazing

L40/260 Bead-fixed single-glazing

L40/310 Bead-fixed single-glazing

L40/330 Bead-fixed single-glazing

L40/350 Bead-fixed single-glazing

L40/370 Bead-fixed insulating glass units

L40/371 Bead-fixed insulating glass units

L40/372 Bead-fixed insulating glass units

L40/380 Bead-fixed insulating glass units

L40/381 Bead-fixed insulating glass units

L40/40 Putty-fronted single-glazing

L40/410 Single-glazing into grooves

L40/430 Single-glazing into grooves

L40/450 Single-glazing into grooves

L40/470 Zipper gasket glazing

L40/490 Single-sided gasket glazing

L40/50 Bead-fixed single-glazing

L40/530 Internal tape glazing

L40/55 Bead-fixed insulating glass units

L40/550 Glass mirrors

L40/57 Bead-fixed insulating glass units

L40/58 Bead-fixed insulating glass units

L40/90 Internal tape glazing

Specification data - Thermally toughened glass sheets

Product Reference

SatinDeco

SatinDeco UltraClear (Low Iron base glass)

SatinDeco Lami

SatinDeco Lami Colour

SatinDeco Mirror

Thickness:

See Options for all Standard, Mirror and Laminated thicknesses.

Standard product features

Size:

- Manufacturer's standard (other sizes available):

  • Jumbo: 3210 x 6000 mm.
  • Split: 3210 x 2250–2550 mm.

Product Options

Product reference:

- SatinDeco Lami:

A translucent laminated safety glass.

-SatinDeco UltraClear:

The translucent appearance of SatinDeco produced on a Low Iron base glass, which removes any hint of green/blue which can be apparent in clear float, and providing a crystal like edge detail to the glass.

- SatinDeco Mirror:

Mirrored glass offered in a variety of thicknesses. Applications include mirrors on wardrobe doors, in bathrooms, decorative walls, furniture applications, projection screens and display cases.

Thickness:

  • SatinDeco: 3, 4, 5, 6, 8, 10, 12 or 15 mm.
  • SatinDeco UltraClear: 3, 4, 5, 6, 8, 10, 12, or 15mm.
  • SatinDeco Mirror: 3, 4, 5, 6 or 8 mm.
  • SatinDeco Lami: 6.4, 6.8, 7.5, 8.4, 8.8, 9.5, 10.4, 10.8, 11.5, 12.4, 12.8 and 13.5 mm. Other thicknesses and PVB interlayers available – contact manufacturer for details.
