Sarlon Uni

Name: Sarlon Uni
Brand: v9DFe6oJ1MnGdQqvvCxoBV
SKU: hJLpSCTA8fPYofRh94jgGe

Forbo Flooring Systems UK Ltd

Acoustic vinyl flooring sheet.

Jump to:

+44 (0)800 093 5258 www.forbo-flooring.co.uk

Application

Internal use, all busy commercial and public sector locations.

Description

Forbo’s Sarlon acoustic vinyl is a resilient floor covering complying with EN 651/ISO 11638 Resilient floor coverings – Heterogeneous PVC flooring on foam specification.

Features and benefits:

High acoustic performance offering sound reductions of both 15dB and 19dB.

100% of the electricity used is from a renewable source.used is from a renewable source.

Meets the requirements of EN 14041.

Can be combined with Sarlon Code Zero, Sarlon Topography and Sarlon Dégradé.

Application:

Internal use, all busy commercial and public sector locations.

General information

Material	PVC Sheet with Foam Backing
Shape	Sheet
Size	2 M width
Uniclass 2015	Pr_35_57_71_67 Polyvinyl chloride (PVC) sheetsPrimary
CAWS	M50/150 Sheeting M50/20 Sheeting

Specification data - Polyvinyl chloride (PVC) sheets Enhanced data

Product Reference	Sarlon Acoustic Vinyl 15dB Sarlon Acoustic Vinyl 19dB
Standard	BS EN 651
Use Class (to BS EN ISO 10874)	Commercial: 34, very heavy; light industrial: 43, heavy
Slip resistance	-
Slip resistance to UKSRG pendulum test	PTV dry : >50
(to DIN51130)	R9
Slip resistance (to EN 13893)	DS - μ ≥ 0.30
Width	2 M
Impact sound reduction (to EN-ISO 717-2)	15 dB 19 dB
In-room impact noise (to NF S 31-074)	Ln,e,w < 65 dB, Class A
Sound absorption (to EN-ISO 354 and EN-ISO 11654)	αw = ± 0.05
Total Thickness (to EN-ISO 24346)	2.6 mm (0.7 mm wear layer) 3.4mm (0.67 mm wear layer)
Colour and pattern	Not required 430817/420817 blue 430827/420827 teal 430818/420818 avocado 430808/420808 lime 430811/420811 grey beige 430814/420814 taupe 430816/420816 scarlet 430806/420806 apricot 430825/420825 buttercup 430801/420801 pearl 430812/420812 light grey
Total weight (to EN ISO 23997)	2.700 kg/m2 2.900 kg/m2
Dimensional stability (to BS EN ISO 23999)	<0.1%
Residual indentation (to EN-ISO 24343-1)	~0.05 mm ~0.08 mm
Abrasion resistance (to BS EN 660-2)	Group T
Castor chair continuous use (to ISO 4918 and EN 425)	Yes
Lightfastness (to ISO 105-B02)	≥7
VOC emissions (to ISO 16000-9)	TVOC after 28 days- < 100 μg/m3
Reaction to fire (to BS EN 13501)	Bfl-s1- 15 dB Cfl-s1- 19 dB
Body voltage (to EN 1815)	<2 kV
Thermal conductivity (to BS EN 12524)	0.25 W/(m·K)

Standard product features

Colour:

Twelve colours available.

Feature:

High acoustic performance.

Material:

PVC Sheet with Foam Backing.

Shape:

Sheet.

Size:

2 M width.

Warranty:

Ten years.

Recycled content:

0%.

Recyclability:

100%.

Embodied Carbon:

13.9 Kgs Co2 Eq / m2.

Red listed materials:

PVC.

Country of origin:

Netherlands.

Environmental information

Embodied carbon	13.9 Kgs Co2 Eq / m2
Recyclability	100%
Recycled content	0%
