Safety Backed Glass Mirrors
Verified by manufacturer 4 months ago
G4530 - 450 x 300 mm
G4530 - 450 x 300 mm
Silver glass mirrors. Safety backed to BS6206 Class B & C / BS EN 12600. Made to measure sizes available. Custom specifications available.
Application
Suitable for internal applications.
Typical applications include:
- General Commercial & Domestic Use.
- Schools
- Universities
- Offices
- Hospitality
- Healthcare
- Retail
Description
Safety backed glass mirrors for internal use. Used in a wide range of applications.
The safety backing conforms to BS6206 class B & C, and helps to hold the shards together in the event of a breakage.
Features and benefits:
- Safety backed to BS6206 class B & C / BS EN 12600 2B2.
- 4 mm or 6 mm thickness.
- Supplied with a flat polished edge as standard.
- Available in a range of aluminium frames.
- Bespoke shapes and sizes are available.
- Multiple fixing options available.
- Optional bevelled edges from 10-40mm for 6mm thick glass mirrors.
Safety backed glass mirrors must be mechanically fixed. Adhesive fixing is not recommended as only the backing would be bonded to the substrate.
Fixing Options
Screw holes & dome head mirror screws (as standard).
Verity clips
J channel
Safety backed glass mirrors can also be supplied in a range of aluminium frames upon request.
General information
Color | Silver |
Material | Polypropylene Glass |
Shape | Rectangle Square Other |
Length | Bespoke 450 mm 650 mm 800 mm 600 mm |
Width | Bespoke 300 mm 400 mm 450 mm 600 mm |
Uniclass | |
CAWS | L40/550 Glass mirrors N13/438 Mirrors N10/270 Mirrors L40/91 Glass mirrors |
Specification data - Wall mirrors
Classification data | |
Description | Silver glass mirrors. Safety backed to BS6206 Class B & C / BS EN 12600. Made to measure sizes available. Custom specifications available. |
Product reference | Safety Backed Glass Mirrors. |
Standards | To BS EN 1036-2. |
Material | Glass/ polypropylene. |
Size | |
Height | 450 mm. |
Width | 300 mm. |
Thickness | 4 mm. 6 mm. |
Finish | Silvered. |
Frame | |
Material | Manufacturer guidanceAvailable in a range of aluminium frames. Consult manufacturer and insert requirements. |
Profile | Flat, polished edge. Guidance for specification option: As standard. Bevelled custom. Guidance for specification option: Custom bevelled edges are optional. Contact manufacturer and insert requirements. |
Treatment | Polished. |
Provision for fixing | Screw holes and dome head mirror screws. Verity clips. J channel. Aluminium frame. Guidance for specification option: All glass mirrors can be supplied with a range of different aluminium frames. Contact manufacturer and insert requirements. |
Standard | To BS 6206, safety glass, class B and C. |
Backing | Polypropylene safety backing tape. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Polypropylene Glass |
Literature
Literature type
BS6204 Conformity Certificate
Safety Backing Technical Specification
CSM Safety Glass Mirror Specification Rev01
Safety Backed Glass Mirrors O&M Manual Rev02
