S16-SU Sliding Door Drive
Description

BLASI SU sliding door drives cater for door opening sizes of up to 4000 mm in width. The maximum weight of the door leaves is up to 1 x 200 or 2 x 200 kg. A depth of at least 200 mm is required for installation. Sloping doors, heavier leaves and larger opening widths are available on request.

General information

Uniclass 2015

Pr_30_36_59_15 Controlled door closersPrimary

CAWS

L20/520 Sliding doors

Specification data - Controlled door closers

Product Reference

S16-SU Sliding Door Drive

Standard product features

Dimensions (w x d, minimum):

350 x 200 mm.

Circuit voltage:

230 V AC, 50/ 60 Hz.

Power consumption:

  • 15 W standby.
  • 250 W rated power.

Door leaf weight (maximum):

1 x 200 kg/ 2 x 200 kg.

Passage dimensions (w x h, maximum):

4000 x 5000 mm.

Product Options

Adjustable parameters:

  • Hold open time: 0–60 s.
  • Opening speed: Up to 0.7 m/s.
  • Closing speed: Up to 0.7 m/s.

Protection:

IP54.

Operating conditions:

  • Ambient temperature: -15–50°C.
  • Humidity range: Up to 85% relative humidity, non-wetting.
  • Wind load: Wind load design depends on a range of parameters.
