RX Surface Mounted Air Curtains - Wireless Controlled
Verified by manufacturer 3 months ago
RX Surface Mounted Air Curtains - Wireless Controlled.
Application
Suitable for shops, hotels, offices and other commercial.
Description
A welcoming curtain of warmth in shops, hotels, offices and other commercial premises with the added benefit of energy saving and comfort control.
Features and benefits:
- 3kW, 4.5kW and 6kW models.
- 634 mm and 1040 mm widths.
- Wall mounting bracket supplied for ease of installation and angular adjustment.
- Suspended, wall or trunking mounted.
- Wireless controlled by a separately purchased advanced single zone controller.
- Compatible with CRXSL and LC controllers.
- Fan only setting for air circulation.
- Automatic safety cut-out for thermal overload protection.
- Finished in white.
Included in object:
- HE7402RX.
- HE7420RX.
- HE8320RX.
- HE7426RX.
General information
Color | White |
Finish | Powder-coated |
Material | Steel Manufacturer guidanceZinc coated. |
Shape | Rectangle |
Length | 115 mm Manufacturer guidanceDepth |
Width | 634 mm 1040 mm |
Height | 210 mm |
Warranty description | One year Manufacturer guidanceAll products have a one year warranty which is backed by our nationwide customer care service, offering full spares and field support. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 2 |
 IFC | - | 2 |
Literature
RX Surface Mounted Air Curtain data sheet
HE7402RX HE7420RX user instructions
HE8320RX HE7426RX user instructions
