Ronafix SBR Underfloor Heating Screed Admixture

Verified by manufacturer 5 months ago

Ronacrete Ltd

Pre-packed polymer modified screed for underfloor heating systems.

Jump to:
BOS
+44 (0)1279 638700 Website

Application

Suitable for laying floor screeds on underfloor heating systems.

Description

Ronafix Underfloor Heating Screed is supplied as a pre-packed polymer modified, ready to use mortar for laying floor screeds on underfloor heating systems. Supplied complete as a bag of dry components and a bottle of polymer gauging liquid.


Features and benefits:

  • Pre-packed factory formulation for consistent high performance.
  • For use with underfloor heating systems.
  • High early strength and fast drying allows earlier commissioning of heating systems.
  • 45 mm minimum thickness with 16 mm heating pipes.
  • Requires 25 mm cover over heating pipes.
  • Ready for foot traffic after 24 hours.
  • Rapid drying; can receive floor coverings such as vinyl, tiles and carpet after 10 days at 50 mm thick.
  • High resistance to passage of water and water vapour.
  • Meets the requirements of Category A (Very Heavy Traffic) of BRE Drop Hammer Test in accordance with BS 8204-1:1999.
  • Meets the requirements of BS 8204-1, Category C floating screeds at 45 mm.
  • Unaffected by continued exposure to freeze and thaw cycling.

General information

Color

Grey

Material

Styrene-butadiene rubber (SBR)

Guidance for specification option:

Polymer modified cement mortar.

Uniclass

Pr_35_31_06_12 Cementitious levelling screed mixesPrimary

CAWS

M10/17 Proprietary polymer modified wearing screeds

M10/185 Proprietary polymer modified wearing screeds

Specification data - Cementitious levelling screed mixes

Minimum thickness

45 mm.

Guidance for specification option:

With 16 mm heating pipes.

Setting time

24 hours: Foot traffic, 10 days: Can receive floor coverings

Guidance for specification option:

Floor coverings include vinyl, tiles and carpet, at 50 mm thick screed.

Cover

25 mm.

Guidance for specification option:

Minimum over heating pipes.

Impact resistance

Category A.

Guidance for specification option:

Very heavy traffic.

Manufacturer guidance

To BRE Drop Hammer Test in accordance with BS 8204-1: 1999.

Mortar screed

Category C.

Guidance for specification option:

Floating screeds at 45 mm.

Manufacturer guidance

Meets requirements of BS 8204-1.

Sustainability data

Material

Styrene-butadiene rubber (SBR)

Guidance for specification option:

Polymer modified cement mortar.
