Verified by manufacturer 3 months ago
ISO 14001 Environmental Management Systems
Certificate type
ISO 9001 Quality Management
Certificate type
Chain operated roller blind for small to medium blinds.
Suitable for use in a range of applications, including:
A chain operated roller blind supplied assembled, made to measure.
Features and benefits:
Material | Aluminium Guidance for specification option: Headrail and barrel. Fabric Guidance for specification option: Blind. |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Five year Manufacturer guidanceHardware warranty. |
Uniclass | |
CAWS | N10/240 Blinds |
Product range |
Standards | To BS EN 13120. |
Position | Ceiling/ top fixed.Wall/ face fixed. |
Headrail | |
Material | Anodized aluminium. |
Colour | White.Guidance for specification option: (RAL 9016) headrail. |
Blinds | |
Material | Fabric.Guidance for specification option: A wide range of Silent Gliss® fabrics is available; consult manufacturer for details. |
Colour | Guidance for specification option: Insert requirement, various fabrics available, consult manufacturer for information. |
Pattern | Guidance for specification option: Insert requirement, various fabrics available, consult manufacturer for information. |
Tube | |
Material | White powder coated aluminium. |
Diameter | 41 mm.Guidance for specification option: Support tube reference: 10531. |
Operation | Chain operated, left or right hand operation. |
Operating effort | Class 1. |
Testing | Class 2. |
Mechanism endurance | 5000 cycles. |
Accessories | None.Adustable end stop.Guidance for specification option: For upper or lower limits setting after installation. Bottom bar (fascia and headbox).Guidance for specification option: 11442. Concealed headbox (small).Guidance for specification option: 11433. Concealed headbox cover profile (small).Guidance for specification option: 11434. Concealed headbox (large).Guidance for specification option: 11533. Concealed headbox cover profile (large).Guidance for specification option: 11534. Continuous installation profile.Fascia installation profile (small).Guidance for specification option: 11430. Fascia profile round (small).Guidance for specification option: 11431. Fascia profile square (small).Guidance for specification option: 11432. Fascia installation profile (large).Guidance for specification option: 11530. Fascia profile round (large).Guidance for specification option: 11531. Fascia profile square (large).Guidance for specification option: 11532. Headbox side channels.Guidance for specification option: 11542. Integral child safety device or chain break.Metal design brackets.Rectangular bottom bar and endcover.Guidance for specification option: 10633/10635. Oval bottom bar and endcover.Guidance for specification option: 10634/10637. Side by side (unconnected).Side guides.Guidance for specification option: For securing the fabric or up to 15° incline. Stop controller.Guidance for specification option: Halts the blind at any given position - ideal for tall windows or multiple blinds stopping at the same height. |
Execution | Installing blinds. |
Type | Single. Double. Guidance for specification option: (Unconnected). |
Fixing | Bracket covers. Guidance for specification option: Ref 10574/10575. Brackets. Guidance for specification option: Ref 10542/10543. Ceiling brackets. Guidance for specification option: Ref 3044 or 10539. Continuous headrail. Guidance for specification option: Ref 10534. |
Bottom bar material/ Colour | Silver anodized aluminium. White powder coated aluminium. |
Maximum weight | 3 kg. |
ShapeDescription | Circular barrel with round bottom bar and endcover. |
Barrel diameter | 41 mm. |
Barrel | Anodized aluminium. Manufacturer guidanceBarrel material. |
Material | Steel with plastic bracket covers. Manufacturer guidanceBracket material. |
Size | 46 x 43 mm. Guidance for specification option: (Width x height). Manufacturer guidanceBrackets size |
Bottom bar | Round. Guidance for specification option: 21 mm. Rectangular. Guidance for specification option: 13 x 25 mm. Oval. Guidance for specification option: 14 x 25 mm. |
Material | Stainless steel. Manufacturer guidanceChain material. |
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Recyclability | Guidance for specification option: Aluminium is a recyclable material. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 25 % Guidance for specification option: % minimum post recycled aluminium. |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
Platform | Compatible | Version |
---|---|---|
![]() | Revit 2016 | 4 |
![]() | - | 4 |
