Rockfon® Fibral™ Multiflex Baffle

Rockfon® Fibral™ Multiflex Baffle

Rockfon

Baffle which enables creative design solutions and acoustic control for areas where frequent or unhindered access to services is required.

Jump to:
+44 (0)208 2227457 www.rockfon.co.uk
Description

Suited to thermal mass areas and where there is a need to maintain natural light. The vertical installation enables creative design solutions and provides good sound absorption.

Fibral baffles have a smooth, white painted surface and white painted steel end and top cappings. The steel cappings are right angled U-sections with punched holes and built-in clips making the baffle suitable for different installation methods.

General information

Uniclass 2015

Pr_35_93_13_53 Mineral fibre infill unitsPrimary

CAWS

K40/10 Suspended ceilings

K40/115 Unit/ modular suspended ceiling system

K40/265 Infill units

Specification data - Mineral fibre infill units

Product Reference

Rockfon® Fibral™ Multiflex Baffle

Module size

1200 x 300 mm

1200 x 450 mm

1200 x 600 mm

Standard product features

Tile edge and grid:

Multiflex: Use with Rockfon System Baffles.

Fire performance:

Can withstand more than 1000°C for more than 120 minutes without melting.

Reaction to fire:

To BS EN 13501-1, Class A1.

Humidity resistance and dimensional stability:

  • Dimensionally stable, even at humidity levels of up to 100% RH.
  • As the humidity inside a building has no influence on Rockfon ceiling tiles, the ceiling can be installed at all temperatures ranging from 0-40ºC. No acclimatisation is necessary.
  • Retains superior properties even in infrequently heated and unheated rooms.
  • Precautions should be taken to avoid condensation risks.

Light reflection:

In accordance with DIN 5036-3, Rockfon White has 72% diffuse light reflection.

Demounting:

Rockfon Fibral Multiflex Baffles can be demounted.

Cleaning:

Can be vacuum cleaned with a soft brush attachment.

Hygiene:

Stone wool is an inorganic material which is not attacked by rot, fungi or bacteria. This makes for a cleaner and healthier indoor environment.
