Rockfon® OneFrame

Verified by manufacturer 4 days ago

Rockfon

The OneFrame is a frame for creating a suspended element. It fits edge acoustic tiles (A, E, X, DAEX).

Jump to:
+44 (0)208 2227457 Website

Application

Suitable as islands, open plenum or corridor solutions. Application areas include:

  • Office.
  • Leisure.
  • Retail.
  • Education.

Description

Rockfon OneFrame is an adaptable multi-panel island that provides, depending on the choice of tile, a semi concealed, visible or concealed look. It is available in two colours, matt white and matt black seamlessly aligned with the matt grid colours and consists out of corner pieces together with extension profiles in various lengths giving the flexibility to create small to very big island and corridor applications.

Features and benefits:

  • OneFrame fits various tiles (A, E, X, DzNL).
  • All in one package.
  • Suitable to create islands and corridor solutions in modular dimensions and various lengths.
  • Adjustment on site possible.
  • Minimum dimension: 1800 x 1800 mm.
  • Available in two colours: matt white and matt black.

Combatable edge details:

A, E, X and Dznl/A24-edges.

Compatible grids:

T24, T15, T35 and 19 mm.

General information

Color

White

Black

Finish

Matt

Painted

Material

Aluminium

Shape

Rectangle

Length

600 mm

1200 mm

1800 mm

2400 mm

3000 mm

Show more

Height

80 mm

Uniclass

Pr_20_85_32_22 Demountable suspended ceiling gridsPrimary

CAWS

K40/260 Perimeter trims

K40/250 Suspension system

K40/115 Unit/ modular suspended ceiling system

K40/10 Unit/ modular suspended ceilings

Specification data - Demountable suspended ceiling grids

Grid type

-

Exposed

-

Manufacturer guidance

Insert requirements or omit.

Concealed

-

Manufacturer guidance

Insert requirements or omit.

Semi-concealed

-

Manufacturer guidance

Insert requirements or omit.

Components

Main runner - Oneframe extension kit 600.
Main runner - Oneframe extension kit 1200.
Main runner - Oneframe extension kit 1800.
Main runner - Oneframe extension kit 2400.
Main runner - Oneframe extension kit 3000.
Main runner - Oneframe extension kit 3600.

Manufacturer guidance

Product group: OF EXT.

Height: 80 mm.

Lengths: 600, 1200, 1800, 2400, 3000 and 3600 mm.

Material

Glass reinforced plastic (GRP).

Finish as delivered

-

Colour

Matt white, RAL 9003 (11W).

Guidance for specification option:

L value: 93.

Gloss: 3.3 at both a 60° and 2.8 at 85° angle.

Matt black, RAL 9004 (88B).

Guidance for specification option:

Gloss: 4.4 at 60° angle and 16 at 85° angle.

Corrosion resistance

Class B.

Corners

OF OCK - Oneframe outside corner kit, 910 x 80 mm.

Accessories

Not required.

TSK - Oneframe twist wire suspension.

FGC - Oneframe frame to grid clip.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Belgium

Material

Aluminium

Recyclability

Fully recyclable
