Application

Suitable for room to room sound insulation and absorption in areas such as:

  • Office environments where privacy and acoustic comfort are important.
  • Healthcare.
  • Education.

The recommended installation system for this product is Rockfon® System dB™ - consult manufacturer for details.

Description

Dual layer stone wool tile with an inner high performance membrane for sound insulation and absorption.

Features and benefits:

  • Class A sound absorption and Class A2-s1,d0 fire safety.
  • Attractive to the visible side, with a smooth, deep matt finish.
  • The 50 mm thickness and high performance membrane on the reverse side help to reduce the transmission of noise from room to room.
  • Lightweight.
  • Durable, ensuring resistance to dirt and everyday wear and tear, extending the product lifetime.
  • Easy to clean with a damp cloth or vacuum cleaner.
  • Easy to install and cut.
  • Available in concealed, semi-concealed and visible grid options.
  • Hygienic; stone wool provides no sustenance to micro-organisms.
  • Includes durable painted edges.
  • Can be fully recycled.

Application:

Suitable for room to room sound insulation and absorption in areas such as:

  • Office environments where privacy and acoustic comfort are important.
  • Healthcare.
  • Education.

The recommended installation system for this product is Rockfon® System dB™ - consult manufacturer for details.

General information
Uniclass 2015
Pr_35_93_13_53 Mineral fibre infill unitsPrimary
Specification data - Mineral fibre infill units
Product Reference

Rockfon Blanka® dB 46

Module size

600 x 600 mm

1200 x 600 mm

Edges

A24

D

Available with 600 x 600 mm only.

E15

E24

Standard product features

Colour:

Super white (L value: 94.5).

Thickness:

50 mm.

Weight:

7.9 kg/m².

Surface finish:

  • Visible side: Smooth, deep matt, white painted fleece.
  • Rear side: Back fleece

Sound absorption:

To ISO 11654: 0.95 αw. Class A.

Sound insulation:

  • Direct sound insulation: 25 dB Rw.
  • Room to room sound insulation: 46 dB.

Reaction to fire:

To BS EN 13501-1: A2-s1,d0.

Fire performance:

Some sizes and edge details of Rockfon® Blanka™ dB 46 can be used with various Chicago Metallic grids and Rockfon systems to create a 30 minutes fire protecting ceiling in accordance with BS 476 Part 21 and Part 23. They can also be used to create a 30 minutes fire protecting membrane ceiling (integrity only) in accordance with BS 476 Part 22 – consult manufacturer for details.

Humidity and sag resistance:

  • Dimensionally stable, even at humidity levels of up to 100% RH.
  • No visible deflection in high humidity.

Light reflection:

Light reflection: 87% (Light Diffusion: >99%).

Demounting:

Rockfon tiles with A, D and E edges can be demounted.

Thermal insulation:

  • Thermal conductivity (K-Value): 40 W/mK.
  • Thermal resistance (R-Value): 1.25 m²K/W.

Cleaning:

  • Vacuum: The surface can be vacuum cleaned with a soft brush attachment.
  • Damp cloth: The surface can be cleaned using a damp cloth or sponge with a slightly alkaline detergent (pH between 7 and 9) without alcohol, ammonia or chlorine (this may render the surface slightly shinier, so a thorough clean is recommended).
  • Wet scrub resistance to EN ISO 11998: 2007: Class 1.

Emissions:

Awarded the Finnish M1 emission classification for building materials and the Danish Indoor Climate Label for low VOC emission products.

Compatible edges, grids and systems:

  • A24: Use with Chicago Metallic T24 2890 Click Grid to create Rockfon® System T24 A™.
  • D: Use with Chicago Metallic T24 2890 Click Grid to create Rockfon® System T24 Stepped Z D™ or Rockfon® System XL T24 D™.
  • E15: Use with Chicago Metallic T15 2790 Click Grid to create Rockfon® System T15 E™.
  • E24: Use with Chicago Metallic T24 2890 Click Grid to create Rockfon® System T24 E™.
