Retrofit Wind Uplift Paving Clip – RFC-WU

Name: Retrofit Wind Uplift Paving Clip – RFC-WU
Brand: RYNO
SKU: eHv1StaZfUWUpFBHmYvH2E

Verified by manufacturer 5 months ago

RYNO

Third party certifications:

ISO 45001 Health and Safety Management
Certificate type
ISO 9001 Quality Management
Certificate type

Paving clip crafted from stainless steel for durability and sustainability. Can be installed on paving that has already been laid, without the need to lift or move any pavers.

Jump to:

+44 (0)203 967 3500 Website

Application

Suitable for commercial applications including raised paving with a gap of ≥4 mm.

Compatible systems include:

BalcaSmart® IGNO Pedestal Paving System.
TerraSmart® Pedestal Paving System.
TerraSmart® IGNO Pedestal Paving System.

Description

The Retrofit Wind Uplift Clip for paving can be installed on raised paving areas that have been laid in the past, without having to lift or move the paving. Designed to fit in a 4 mm paver gap, the clip ties the paved surface together and provides an effective wind uplift restraint.

Features and benefits:

Retrofit capability, avoids the need for re-installation of paving, saving significant cost and time.
Discreet dome head fixing for user comfort.
Removable tether for easy application.
Product tested to a maximum of 6000 Pascals (6 kPa) in pulsed cycles.
No detrimental effects to any of the systems were found and no failures were observed during testing.
Tested in accordance with EOTA Technical Report TR005: 2003.

General information

Color	Silver
Finish	Stainless steel
Material	Stainless steel
Shape	Other
Length	35 mm
Width	20 mm Guidance for specification option: Top washer. 25 mm Guidance for specification option: Bottom washer. Manufacturer guidance Diameter.
Height	0.85 mm Guidance for specification option: Top washer. 2.5 mm Guidance for specification option: Bottom washer. Manufacturer guidance Thickness.

Uniclass	Pr_20_85_47_22 Decking and paving pedestalsPrimary
CAWS	Q55/395 Support pedestals Q25/480 Support pedestals J41/90 Precast concrete paving slabs J42/467 Support system for precast concrete paving slabs Q37/460 Support pedestals J21/467 Support system for precast concrete paving slabs J41/467 Support system for precast concrete paving slabs

Specification data - Decking and paving pedestals

Material	Washers: A4 stainless steel. Flanged head fixing: A2 stainless steel.

Reaction to fire	A1.
Dimensions	Top washer: 20 x 0.85 mm. Bottom washer: 25 x 2.5 mm. Flanged head fixing: M3 x 35 mm.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Stainless steel
Manufacturing plant location	United Kingdom
Recyclability	Recyclable
