A quartz trowelled aggregate resin flooring system. Used within areas that require hard wearing properties, exceptional bond, impermeable without any pinholes, tailored slip resistance
This system is suitable for wet areas such as, food and beverage production, manufacturing areas, commercial kitchens, toilet facilities, leisure facilities and external areas such as steps and walkways.
A quartz trowelled aggregate system
A decorative methyl methacrylate (MMA) resin screed, typically laid at 4–6 mm. Coloured quartz aggregate is broadcast into the resin rich screed to create a textured, slip resistance finish.
Seal coats are then applied to totally encapsulate the coloured quartz within the system.
Features and benefits:
Color | Blue Green Grey Red Yellow |
Finish | Textured |
Material | Methyl methacrylate Methyl methacrylate resin. |
Shape | Formless |
WarrantyDescription | Ten year |
Uniclass | |
CAWS | M12/110 Resin flooring M12/10 Resin flooring |
System performance | Slip resistance (PTV): To BS 7976, 74 dry, 69 wet.Using TRL pendulum test method. |
Substrate | - |
Testing | Bond, moisture and compressive tests undertaken by Degafloor Approved Installer. |
Preparation | Mechanical preparation required. |
Levelling screed | Not required. |
Primer | Degafloor B71 primer.Degafloor 112 primer.Degafloor 115 primer.Degafloor 117 primer. |
Resin flooring | Applied by pin rake, resin and quartz mixed. |
Reinforcement | Not required. |
Surface treatment | Seal coats. |
Movement joints | - |
Type | Degafloor Flexible Resin Jointing Compound. |
Resin skirtings and upstands | To match flooring system and colour. |
Execution | Applied by rake and roller. |
Abrasion resistance | Weight loss <3000 mg. |
Adhesion strength | ≥2.0 N/mm². |
Finish | Textured. |
Material | MMA. Methyl methacrylate resin. |
Bond strength | ≥B2.0. |
Capillary absorption | W <0.1 kg/(m²·h^0.5). Capillary absorption and permeability to water. |
Carbon dioxide permeability | SD >50 m. |
Chemical resistance | Reduction in hardness <50%. |
Colour | Autumn Green. Cornflour Blue. Mussel Grey. Ocean Blue. Oyster Grey. |
Cure time | Two hours. |
Impact resistance | Class I, ≥IR 4. |
Reaction to fire | Not tested. |
Release of corrosive substances | SR. |
Standard | To BS EN 1504 and BS EN 13813. |
Third-party certification | To British Board of Agrément-certified (20/Q064). |
Water vapour permeability | Class III. |
Wear resistance | ≤AR 0.5. |
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | Germany |
