Resin Bound Surfacing - Porous Surfacing
Verified by manufacturer 4 months ago
Alaskan Tundra VT
Alaskan Tundra VT
BBA Agrément Certificate
Certificate type
Vuba resin bound surfacing is a permeable, SuDS compliant decorative paving system. It can be used for both pedestrian and vehicular traffic areas to create a luxurious and durable finish.
Application
Suitable applications include:
- Venues and stadiums.
- Housing developments.
- Private driveways.
- Public buildings.
- Hospitality.
- Pathways.
Description
Vuba resin bound surfacing is a permeable, SuDS compliant decorative paving system. Vuba is suitable to provide an environmentally friendly, hardwearing and design-led solution for housing developments, public buildings, private driveways and more.
Vuba resin binder is an aliphatic two component polyurethane stone encapsulation binder.
Features and benefits:
- Vuba Resin UVR is a UV resistant hybrid polyurethane resin binder.
- SuDS compliant.
- Suitable for vehicles.
- Exclusive colours.
General information
Color | Beige Cream Grey Brown Black |
Finish | Other |
Material | Polyurethane (PUR) Resin Stone |
Shape | Formless |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | 15 year |
Uniclass | |
CAWS | Q26/260 Resin bound stone aggregate surfacing Q23/20 Resin bound aggregate surfaces |
Specification data - Resin-bound mixed aggregate surfacings
Aggregate | |
Type | Bound surfacing decorative aggregates. |
Size (nominal) | 6 mm. |
Colour | Alaskan Tundra VT. |
Binder | |
Type | VUBA Resin Binder UVR.Guidance for specification option:
|
Colour | Clear. |
Slip resistance – water wet (minimum) | PTV of 74. |
Hardness | 72 ShD. |
Tensile strength | 22.3 ShD. |
Elongation | 67.2%. |
Tear strength | 18.8 N/mm. |
Density | 1.02 g/cm³. |
Application temperature range | 5°C to 30°C. |
Cure time | 24 hours. |
Shelf life | 12 months. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Third party certifications
Literature
Aftercare and Cleaning Guide
Moisture Tolerant Resin Data Sheet
MSDS Sheet Resin Part A
MSDS Sheet Resin Part B
Slip Resistance Test Results
Vuba Resin Bound Brochure
Vuba Resin Bound Colour Swatches
Resin Bound Surfacing Base Build Up
Resin Bound Tree Pit Base Build Up
