Resan® Pan – Less Abled - WC Pan
Verified by manufacturer 4 months ago
372561 – Bolt-to-floor, white seat
372561 – Bolt-to-floor, white seat
Damage resistant, raised height WC pan for the less abled with a polished or matt resin finish.
Application
Suitable for installation within custodial, healthcare and commercial environments.
Description
WC pan with modern styling and fully rimless hygienic flush design, with no ledges or steps within the internal bowl shape, reducing the chances of staining sanitaryware as water is prevented from staying on surfaces where lime scale can build up.
This raised height WC is considered as ‘comfort height’ being 480 mm high rather than the standard 415 mm.
An extension box can also be provided (Reference: 372564) which extends the projection of the pan out from the wall to 750 mm from the standard 500 mm. With this additional extension box the WC pan is compliant with Approved Document M.
Features and benefits:
- Damage resistant polished polymer resin.
- Non-flammable.
- Approved Document M compliant when with extension box.
- 'Comfort height' height seat.
- UK Ministry of Justice safer cell approved for bolt to wall fixing.
- Suitable for less-abled users.
- Non-Flammable - BS476 Part 6 and 7; Class 0 and Class 1.
- ISO EN 19712-3-2007 Rated 5 for durability, stain resistance and cigarette burns.
- BS EN 997 6/4 L and 5/3 flush approval.
- BREEAM rated
- CE marked.
General information
Color | White Blue Grey |
Finish | Matt Gloss |
Material | Polymer Resin |
Shape | Oval |
Length | 499 mm |
Width | 395 mm |
Height | 480 mm |
Warranty description | Five year |
Uniclass | |
CAWS | N13/311 Unisex accessible WC equipment packages (Document M) N13/10 WC pans and flushing arrangements |
Specification data - WC pans
Standard | To BS EN 997, Class 2. |
Form | Bolt-to-floor. |
Pan height | 480 mm. |
Materials | |
Body | Polymer resin. |
Finish and colour | White matt.White gloss. |
Water supply, outlet and seat holes | |
Water supply | Back inlet. |
Outlet | Horizontal back outlet. |
Seat holes | None, integral seating rim. |
Integral accessories | Integral seat, white. |
Weight | 52 kg. |
Declaration of conformity | BS 476 Part 6: Fire Propagation & Surface Spread of Flame; ISO EN 19712-3-2007 rated 5 for durability; BREEAM rated; CE marked. |
Fixing options | M6 CSK. |
Accessory | Not required. Extension box. Guidance for specification option: Allows product to comply with Approved Document M. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
