NBS Source
reFrame LVT Collection
Compare variants

Application

Suitable for heavy commercial use.

Recommended installation methods:

  • Brick;
  • Ashlar;
  • Herringbone;
  • Stagger.

Description

reFrame is a new woven LVT that brings visual depth and texture to the spaces where we work, play and learn. The collection is a hybrid floor covering that weaves utilitarian purpose with textural appeal, combining hard surface durability with soft surface aesthetics.


Features and benefits:

  • An innovative woven textile that focuses on the structure of the fabric combining hard surface durability and soft surface aesthetics.
  • ExoGuard™ finish coats the surface of the woven fabric for added ease of maintenance.
  • Engineered to resist stains and scuffs while preventing frayed edges.
  • FloorScore® certified.

General information

Shape

Rectangular

Color

Black

Blue

Brown

Cream

Green

Show more

Finish

E

Material

Vinyl

WarrantyDescription

15 year

Commercial limited warranty

Size

230 x 910 mm

Uniclass

Pr_35_57_71_68 Polyvinyl chloride (PVC) tilesPrimary

CAWS

M50/110 Resilient floor tiling

M50/10 Resilient floor tiling

Specification data - Polyvinyl chloride (PVC) tiles Enhanced data

Standard

To BS EN 14041.

Use class

To BS EN ISO 10874, class 33.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

To BS 7976-2, 56 (dry) and 43 (wet).

Surface roughness (Rz) (minimum)

R12.

Size

230 x 910 mm.

Thickness

3 mm.

Colour and pattern

Perception.

Finish:

ExoGuard™ quartz enhanced urethane.

FlammabilityRating

To EN 13501-1, Bfl-S1 (unadhered testing).

Thermal resistance

0.019 m² K/W.

Dimensional stability

To EN 986, ≤0.15%.

Residual indentation

To EN ISO 24343-1, 0.13 mm.

Sound insulation

To BS EN ISO 10140, 6 dB (18 dB with 3 mm underlay).

Sound absorption

To ISO 354, 0.10 αw.

Colour fastness

5-6.

Light reflectance

37.9 (range 32.5–44.2).

Digital objects

Platform Compatible Version Certified to
IFC
-

1

2.1
Revit
-

1

2.1
Download now from NBS National BIM Library
