Ravello - Freestanding Bath

Verified by manufacturer 12 days ago

Victoria + Albert Baths

Freestanding bath, 157 L capacity.

Jump to:
07443186488 Website

Application

Luxury freestanding bath suitable for domestic and hospitality settings.

Description

Modern freestanding bath.


Features and benefits:

  • Bold, straight lines combined effortlessly with gentle curves.
  • Features a void space underneath for waste plumbing.
  • Made with QUARRYCAST™ a unique blend of Volcanic Limestone™ and high-performance resins.
  • Delivers unrivalled strength, durability, and beauty.
  • Available in a range of RAL colours.

General information

Color

White

Finish

Gloss

Material

Limestone

Stone

Shape

Rectangle

Trapezoid

Length

1743 mm

Width

753 mm

Height

597 mm

Warranty description

Eight year

For commercial use.

25 year

For residential use.

Uniclass

Pr_40_20_06_08 BathsPrimary

CAWS

N13/35 Baths

N13/355 Baths

Specification data - Baths

Form

Free-standing.

Materials

QUARRYCAST™ volcanic limestone.

Colour

White.

Size

1743 x 753 mm.

Volume to overflow (maximum)

289 L.

Water supply, overflow and waste holes

-

Water supply

No tap holes.

Tap holes cannot be drilled for this product.

Overflow

No overflow hole.

Drill as required.

Material Finish

Gloss.

Weight

81 kg.

Dimensions – height

597 mm.

Recommended discharge pipe

(Recommended wastes):

Not required.

K-12-xx.

K-17-xx.

K-36-xx.

K-40-xx.

BIM objects

Platform Compatible Version
Revit
-

1

Literature

EU_Ravello_2022

EU_Ravello_2022

Case studies

Matakauri Lodge Queenstown, New Zealand (Ravello)

Matakauri Lodge Queenstown, New Zealand (Ravello)

NoMad Los Angeles Los Angeles, California, USA (Ravello)

NoMad Los Angeles Los Angeles, California, USA (Ravello)
