Application

Can be used in various applications, including:

  • For use as a sound absorbing panel for indoor commercial, residential and marine applications.
  • Suspended from ceilings as grids or baffles or inserted to existing ceiling tile grids.
  • Direct fix wall coverings.
  • Ceiling hung or free-standing room dividing screens.
  • Incorporate into furniture or interiors.

Description

Acoustic wall panel manufactured from recycled polyethylene terephthalate (PET).

Features and benefits:

Good acoustic performance.

Single layer panel with no layer bonding or lamination.

  • Manufactured from 100% polyester fibre, and a minimum of 60% post-consumer recycled waste.
  • Through-colour, and available in 34 colours, which can be mixed and matched to create unique finishes.
  • Offers a range of design possibilities, can be cut to custom shapes, etched and digitally printed.
  • Pinnable.
  • Non-hazardous to health, without chemical binders or additives.
  • Low VOC content.
  • Smooth or textured finish.
  • Recyclable at the end of its serviceable life.

Applications:

Can be used in various applications, including:

  • For use as a sound absorbing panel for indoor commercial, residential and marine applications.
  • Suspended from ceilings as grids or baffles or inserted to existing ceiling tile grids.
  • Direct fix wall coverings.
  • Ceiling hung or free-standing room dividing screens.
  • Incorporate into furniture or interiors.

General information
Finish

Smooth

Textured

Uniclass 2015
Pr_35_93_13_80 Sound attenuator infill unitsPrimary
Specification data - Sound attenuator infill units
Product Reference

Quest Acoustic Panel

Design

As drawing

As reference

Thickness

12 mm

24 mm

Colour

See 'Options' and insert requirements.

Finish

Smooth

Textured

Standard product features

Composition:

100% polyester fibre, manufactured using 60% post-consumer plastic waste.

Panel size:

2400 x 1200 mm.

Weight:

  • 12 mm thickness: 2800 g/m².
  • 24 mm thickness: 5000 g/m².

Noise reduction coefficient (NRC):

  • 12 mm thickness: 0.55 (no air gap); 0.70 (with a 20 mm air gap).
  • 24 mm thickness: 0.75 (no air gap); 0.95 (with a 20 mm air gap).

Fire rating (to BS 5422: 1990):

Class 0.

VOC emissions (to ASTM D5116):

-0.02 mg/m²/hr (after seven days).

Product Options

Thickness:

Tolerance of ±2 mm. Consult manufacturer for details.

Colour:

  • Arizona (12 mm variants only).
  • Atlantic.
  • Azure.
  • Bark.
  • Brick.
  • California.
  • Caramel (12 mm variants only).
  • Claret (12 mm variants only).
  • Cloud.
  • Cobalt (12 mm variants only).
  • Cotton.
  • Forest (12 mm variants only).
  • Fuscia (12 mm variants only).
  • Graphite (12 mm variants only).
  • Latte.
  • Lime.
  • Marble.
  • Midnight (12 mm variants only).
  • Mocha (12 mm variants only).
  • Oak (12 mm variants only).
  • Oyster (12 mm variants only).
  • Pacific (12 mm variants only).
  • Poppy.
  • Regency (12 mm variants only).
  • Royal.
  • Sage.
  • Salmon (12 mm variants only).
  • Sandstone.
  • Slate.
  • Smoke.
  • Steel (12 mm variants only).
  • Stone.
  • Sunbeam (12 mm variants only).
  • Topaz.

Custom colours can be produced to match any RAL code - consult manufacturer for details.
