PUDLO GB Self Seal
Application

Can be used as a gas proof or waterproof membrane. Suitable for:

  • All aspects of waterproofing and gas proofing where a Grade 2 or grade 3 environment is required as part of a single or dual system recommended in BS 8102: 2009.
  • Gas proofing or landfill sites.
  • Radon and methane affected areas.
  • Waterproofing foundation, basements and roofs.
  • Podium decks, lift shafts, car parks and subways.

The membrane should be covered with a cementitious screed or similar protective layer as soon as possible after it has been installed – consult manufacturer for details.

Description

An advanced waterproof membrane, manufactured from an aluminium and cross-orientated high-density polyethylene (HDPE) film and a layer of rubber-modified bitumen adhesive.

Features and benefits:

  • Provides high-performance protection from the passage of methane and radon gas.
  • Good overlap integrity due to bitumen-to-bitumen joint.
  • Quick and easy installation; membrane overlaps can be taped.
  • Flexible, and provides good bonding to the substrate.
  • Non-hazardous.
  • Resistant to dilute acids and alkalis.
  • Provides high protection against surface groundwater and soluble salts such as sulphates and chlorides.
  • Can resist up to 6 m head of water when fully supported.

Applications:

Can be used as a gas proof or waterproof membrane. Suitable for:

  • All aspects of waterproofing and gas proofing where a Grade 2 or grade 3 environment is required as part of a single or dual system recommended in BS 8102: 2009.
  • Gas proofing or landfill sites.
  • Radon and methane affected areas.
  • Waterproofing foundation, basements and roofs.
  • Podium decks, lift shafts, car parks and subways.

The membrane should be covered with a cementitious screed or similar protective layer as soon as possible after it has been installed – consult manufacturer for details.

General information

Uniclass 2015

Pr_25_57_08_08 Bitumen sheetsPrimary

CAWS

D21/350 Gas-retardant membrane

J40/120 Loose laid plastics or rubber sheet damp proofing

J40/140 Loose laid plastics or rubber sheet gas retardant damp proofing

J40/190 Self-adhesive bitumen damp proofing/ tanking

J40/20 Loose laid plastics or rubber sheet damp proofing

J40/40 Self-adhesive bitumen damp proofing

Specification data - Bitumen sheets

Product Reference

PUDLO GB Self Seal

Accessories/ Other requirements

Not required

PS Termination Strap

For interfacing between PUDLO GB Self Seal and PUDLO Membrane BW.

PUDLO Self Seal Primer

For priming concrete surfaces prior to application. Should be applied allowing 100 mm for edge laps and 150 mm for end laps.

PUDLO GB Self Seal Tape

PUDLO Geo Flo

Drainage layer required depending on location of application.

PUDLO Self Seal Reinforced Strip

Standard product features

Length:

19.05 m (-0% to +5%).

Width:

1.05 m.

Weight:

33 kg.

Thickness:

1 mm.

Technical characteristics:

  • Mass (to EN 1849-2): 1100 g/m².
  • Backing thickness: 0.1 mm.
  • Backing type: Laminate.
  • Adhesive thickness: 0.90 mm.
  • Area: 30 m².

- Mechanical properties:

  • Watertightness to liquid (to EN 1928): Pass.
  • Resistance to static load (to EN 12730): 20 kg; pass.
  • Maximum tensile strength, cross direction (CD) (to EN 12311-2): ≥2 N/mm².
  • Maximum tensile strength, machine direction (MD) (to EN 12311-2): ≥2 N/mm².
  • Elongation at break, machine direction (MD) (to EN 12311-2): ≥2120%.
  • Elongation at break, cross direction (CD) (to EN 12311-2): ≥2120%.
  • Durability watertightness against ageing (to EN 1847, method A, 60 KPa): Pass.
  • Durability watertightness against chemicals (to EN 1847, method A, 60 KPa): Pass.
  • Resistance to impact (to EN 12691): ≥500 mm.
  • Resistance to tear (nail shank, cross direction) (CD) (to EN 12310-1): ≥100 N.
  • Resistance to tear (nail shank, machine direction) (MD) (to EN 12310-1): ≥100 N.
  • Reaction to fire (to EN 13501): Class F.
  • Joint strength (to EN 12317-2): ≥30 N.
  • Water vapour transmission (density flow rate) (to EN 1931): 0.013 g/(day m²).
  • Water vapour transmission (resistance factor) (to EN 1931): 238 0000 μ.
  • Methane gas permeability: <0.03 ml/m²/day.
  • Radon diffusion: 5.0 x 10^-14.
