PPG SIGMACOVER® 809 - Two-Component Epoxy Primer
Verified by manufacturer 2 days ago
Two-component, high solids, polyamine adduct cured zinc phosphate epoxy primer/coating for C5 and CX environments.
Application
Suitable for on-site and off-site application by spray, brush and roller on steel structures, providing long term corrosion protection.
Description
Two-component, high solids, polyamine adduct cured zinc phosphate epoxy primer/coating that dries in a flat gloss in a grey or red-brown.
Features and benefits:
- High-performance modified passivation primer and build coat for protective coatings systems.
- Long-lasting protection to steel structures requiring corrosion protection in extreme environmental conditions.
- Suitable for use in offshore and onshore environments with ISO 12944-2 corrosivity categories of C5 and CX (offshore).
- Surface tolerant coating for lower grade of surface preparation for atmospheric exposure.
- Suitable for immersion service without cathodic protection.
- Easy application by brush/roller and (airless) spray.
General information
Color | Grey Red |
Finish | Smooth |
Material | Epoxy Polyamide |
Shape | Formless |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | G10/640 Shop painting G10/630 Galvanizing plus site-applied M60/175 Protective coating M60/195 Special coating G10/650 Site painting G10/65 Shop priming for M60/18 Special coating G10/660 Shop plus site painting G10/638 Shop priming |
Specification data - Solvent-borne metal primers
Classification data | |
Composition | Epoxy, two-pack. Guidance for specification option: Two-component, high solids, polyamine adduct cured zinc phosphate epoxy primer/ coating. |
Colour | Grey. Red-brown. |
Density | 1.7 kg/L. |
Volume solids | 80%. Guidance for specification option: ±2%. |
VOC content | UK PG 6/23(92) Appendix 3, maximum 270 g/L. Guidance for specification option: Directive 2010/75/EU, SED, maximum 159.0 g/kg. |
Dry film thickness | 75–250 µm. |
Drying time | Three hours. Manufacturer guidanceDry to touch. |
Overcoating | Three hours minimum, 28 days maximum for overcoating. |
Curing time | Five days. Manufacturer guidanceFull cure time. |
Sustainability data
Country of product manufacture | Poland |
Manufacturing plant location | |
Material | Epoxy Polyamide |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
Expected Life | Manufacturer guidance25+ years as part of a tested PPG system. |
Literature
PPG SIGMACOVER® 809 - Product Data Sheet
