Power Assisted Door - ASSA ABLOY RD100 Revolving Door
Application

Applications include external, existing and new builds.

Description

Power assisted revolving door.

Features and benefits:

  • Available in different colours including bronze, clear, stainless steel and RAL colours.
  • Mechanical lock.
  • RC3 burglar resistance according to EN1627:2011.
  • Two outer wall designs.

Application:

Applications include external, existing and new builds.

General information

Finish

Anodized, stainless steel clad or RAL finish

Material

Aluminium profiles with glass infill

Shape

Circular system

Size

Dependent on type

Uniclass 2015

Pr_30_59_24_50 Manual revolving doorsetsPrimary

CAWS

L20/500 Manual revolving doors

Specification data - Manual revolving doorsets

Product Reference

Power Assisted Door - ASSA ABLOY RD100 Revolving Door

Third party accreditation

RC3 burglar resistance according to EN1627:2011

Standard

EN16005:2012

Configuration

ASSA ABLOY RD100-3

Diameter 1800-3000 mm.

ASSA ABLOY RD100-4

Diameter 1800-3000 mm.

Materials and finishes

-

Doors

Anodized

Stainless steel clad

RAL

Drum walls

Frame

Slim aluminium profile

Glazing type

Glass outer wall: 4 + 4 mm clear laminated (frame/ slim)

Canopy

Ceiling made from white laminated panels

Activation and control system

-

Type

Manually activated power assisted revolving doorset

Locking mechanism

Mechanical lock on NCD

Mechanical lock on door leaf

Breakout facility

Additional emergency stop button

Accessories

Consult manufacturer and insert requirements.

Standard product features

Colour:

Available in bronze anodized, clear anodized, stainless steel clad or RAL colours.

Features:

Available in different colours including bronze, clear, stainless steel and RAL colours, mechanical lock, RC3 burglar resistance according to EN1627:2011 and has two outer wall designs.

Finish:

Anodized, stainless steel clad or RAL finish.

Material:

Aluminium profiles with glass infill.

Shape:

Circular system.

Size:

Dependent on type.

Digital objects
Platform Compatible Version Certified to
Revit
-

1

1

Download now from NBS National BIM Library
