Powder Coating - Interpon D3020

Powder Coating - Interpon D3020

Third party certifications:
  • QA Certificate

    QA Certificate

    Certificate type

Akzo Nobel Powder Coatings Ltd

A range of hyper-durable coatings designed to meet the most demanding weathering standards including Qualicoat Class 3, GSB Class A, AAMA 2605-05 and 10 Year Florida.

Jump to:
+44 (0) 845 6032401 www.interpon.com
Application

Intended for use on architectural aluminium and galvanized steel.

Description

Hyper-durable, architectural grade powder coatings.

Features and benefits:

  • Provides the highest resistance to UV weathering.
  • Complies with BS EN 12206–1 for applications onto aluminium and BS EN 13438 for applications onto galvanized steel.
  • Complies with the European Qualicoat - Class 3 and GSB specifications.
  • Backed by an extended product performance guarantee.

Application:

Intended for use on architectural aluminium and galvanized steel.

General information

Finish

Solid and metallic

Material

Fluorocarbon

Uniclass 2015

Pr_35_31_68_66 Powder coatingsPrimary

CAWS

H10/10 Patent glazing

H10/115 Patent glazing

H11/110 Curtain walling

H11/130 Sun screens

H11/135 Doors

Show more
Specification data - Powder coatings Enhanced data

Product Reference

Powder Coating - Interpon D3020

Colour

Refer to Akzo Nobel for availability of colours and insert requirements.

Standard

To aluminium: BS EN 12206-1/Qualicoat

To galvanized steel: BS EN 13438

Powder formulation

Fluorocarbon

Accelerated weathering:

Gloss retention: >90% (BS EN ISO 11341, 2000 hours)

Acetic acid salt spray resistance

Blasting <2, infiltration length <4 mm (2000 hours)

Adhesion

Gt0 (2 mm crosshatch)

Buchholz hardness

>80

Chemical resistance

Generally good resistance to acid, alkalis and oil at normal temperatures

Constant humidity resistance

No blistering, creep <1 mm (1000 hours)

Coverage

3-7 m²

Dry film thickness

50-80 micrometres

Erichsen cupping

Pass Qualicoat Class 2 requirements

Fire classification (EN 13501-1)

A2,s1-d0

Flexibility

Pass Qualicoat Class 3 requirements

Gloss level

25-35 gloss units

Impact resistance

Impact power >2.5 NM no detachment after tape pull test

Mortar resistance

No effect after 24 hours

Particle size

Suitable for electrostatic spray

Stoving schedule

20-35 minutes at 190°C, 15-25 minutes at 200°C

Standard product features

Features:

Provides the highest resistance to UV weathering and complies with BS EN 12206–1 for applications onto aluminium and BS EN 13438 for applications onto galvanized steel. Also complies with the European Qualicoat - Class 3 and GSB specifications and backed by an extended product performance guarantee.

Finish:

Matt and metallic.

Material:

Fluorocarbon.

Warranty description:

Up to 40 years (UK application only).

Embodied carbon:

8.81 kg CO2-e.

Environmental information

Embodied carbon

8.81 kg CO2-e

Digital objects
PlatformCompatibleVersionCertified to
IFC
IFC2X3 5 1.3
Revit
Revit 2016 6 2.0
Download now from NBS National BIM Library
Literature
Third party certifications
  • European Qualicoat: Certificate: Class 3
  • GSB: Certificate: Class A
  • AAMA: 2605
