PLE Panel Heaters

Verified by manufacturer 15 days ago

PLE050

Consort Claudgen Variant:

Panel heaters with electronic seven-day timer.

Jump to:
BIM object icon
+44 (0)1646 692172 Website

Application

Suitable for hotels, offices, bedrooms, kitchens, bathrooms and laundries.

Description

These slimline heaters with concealed digital controls have strengthened grilles to increase durability and feature a snap-on bracket on their wall mounting system which allows easy installation and dismounting for cleaning and decorating.


Features and benefits:

  • 0.5 kW, 0.75 kW, 1 kW, 1.25 kW, 1.5k W or 2 kW rating.
  • Seven-day timer with electronic thermostat.
  • Six heating periods per day.
  • Cell battery to backup real time clock.
  • Open window detection.
  • Frost protection setting.
  • Can set comfort and setback temperatures.
  • Very quiet operation.
  • Four large control button with audible and tactile feedback.
  • Electronic lock.
  • Automatic safety cut-out.
  • Splash-proof to IP24.
  • Maintains temperature within 0.7 degrees.
  • 15-minutes Boost feature.


Include in object:

  • PLE050
  • PLE075
  • PLE100
  • PLE125
  • PLE150
  • PLE200/SS


Note: 'SS' denotes stainless steel model.

General information

Color

White

Silver

For PLE200SS stainless steel finish.

Finish

Powder-coated

Material

Zinc coated steel, UL94 V0 ABS plastic side mouldings.

Steel

Plastic

Acrylonitrile butadiene styrene (ABS)

Shape

Rectangle

Length

Depth

93 mm

Width

442 mm

614 mm

720 mm

852 mm

Height

430 mm

Warranty description

One year

All products have a one year warranty which is backed by our nationwide customer care service, offering full spares and field support.

Uniclass

Pr_70_60_36_74 Room heatersPrimary

Product range

Panel Heaters

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0 kg CO₂ eq/unit

Recyclability

This product can be recycled.

Recycled content

Percentage value will vary depending on the product manufactured and the recycle materials available for use to manufacture the product.

90 %

BIM objects

BIM object icon

NBS BIM object standard

This BIM object has been authored to meet the requirements of the NBS BIM object standard.

Find out more about the NBS BIM object standard.

Platform Compatible Version
IFC
-

3

Revit

Revit 2017

3

Literature

PLE Panel Heater data sheet

PLE Panel Heater data sheet

PLE Panel Heater user instructions

PLE Panel Heater user instructions
