Perform Panel
Verified by manufacturer over a year ago
Perform panel is designed for internal use, both in wet and dry rooms in commercial, domestic and public areas.
Application
- Suitable for use in wet and dry rooms in commercial, domestic and public areas.
- Specific uses include bathrooms, wetrooms, shower enclosures and areas that are exposed to water.
- Also suitable for use in some applications requiring hygienic wall cladding - consult manufacturer for details.
- Can be installed directly onto a concrete wall, plasterboard or over existing tiles. Timber framing may be required to achieve the flat surface required for fitting.
Description
Decorative high-pressure laminate (HPL) wet wall panels for internal use in domestic and commercial environments.
Feature and benefits:
- Cost-effective alternative to tiling.
- No grouting required.
- Waterproof: floor-to-ceiling moisture protection.
- Ease of installation - can be cut with hand tools or suitable power tools.
- Low maintenance - laminate surface is best kept clean by using a wet cloth and a mild detergent.
- Versatile and robust.
- Hygienic.
- Range of colours and trims available.
Applications:
- Suitable for use in wet and dry rooms in commercial, domestic and public areas.
- Specific uses include bathrooms, wetrooms, shower enclosures and areas that are exposed to water.
- Also suitable for use in some applications requiring hygienic wall cladding - consult manufacturer for details.
- Can be installed directly onto a concrete wall, plasterboard or over existing tiles. Timber framing may be required to achieve the flat surface required for fitting.
Warranty:
Ten years.
General information
Color | Up to 50 colours available |
Finish | Satin anodised aluminium, chrome, white, black |
Material | High pressure laminates |
Warranty description | 10 years |
Size | 2400 x 600 x 11 mm 2400 x 900 x 11 mm 2400 x 1200 x 11 mm |
Finish | Satin anodised aluminium, chrome, white, black |
Uniclass | |
CAWS | K30/130 Relocatable partition system |
Specification data - Compact or solid grade high-pressure laminate (HPL) boards
Product Reference | Perform Panel |
Type | Nu-LockGuidance for specification option: Tongue and grooved. Square-edged |
Size (h x w) | 2400 x 600 mmGuidance for specification option: Nu-Lock only. 2400 x 900 mm2400 x 1200 mmGuidance for specification option: Standard. |
Core | Moisture-resistant medium-density fibreboard (MDF)WISA plywoodGuidance for specification option: Nu-Lock: 7-ply; Square-edged: 5-ply. |
Pattern/ colour | Guidance for specification option: Extensive range available; consult manufacturer's literature and insert requirements. |
Trim | |
Type | Not requiredBottom trim, whiteEnd capExternal corner, colourInternal corner, colourQuadrant, colourStraight joint, colour |
Colour | Guidance for specification option: See 'Options' below and insert requirements. |
Standard product features | Material: High-pressure laminate (HPL). Thickness: 11 mm. Tolerances:
|
Product Options | Size (h x w): For Nu-Lock panels, 10 mm is lost from the working width at each joint:
Trim: - Type:
- Length: Supplied in standard lengths of 2500 mm. - Colour: Consult manufacturer's literature for further details.
|
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | Revit 2017 | 1 |
 IFC | - | 1 |
