Perforated Lath Roller Shutters

Steel, perforated lath roller shutters, which are robust and have a long life, with little maintenance required.

Features and benefits:

• Curtain: constructed from 76 mm curved perforated galvanized steel laths, with steel end locks fitted to alternate laths to prevent lateral movement.

• Bottom rail: galvanized steel inverted 'tee' section.

• Guides: the side guides are formed from galvanized steel channels and prepared for fixing to the opening structure by means of continuous fixing angles.

• End plates: fabricated from mild steel of adequate thickness relative to door size, and supplied with angles for fixing to the structure.

• Roller: the roller is manufactured from carbon steel tube of sufficient diameter and wall thickness to resist deflection, and is mounted on bearings or cups on each end plate.

• Operation: electrical operation is by means of a single-phase tubular motor. A safety brake is fitted to all shutters where personnel could pass underneath, thus meeting all relevant health and safety requirements. The client should provide a fused spur within 500 mm of the motor position.

• Controls: the standard method of control is by means of internal, wall-mounted push-buttons.

• Casings: coil casings fabricated from galvanized steel sheet are available as an optional extra.

Applications:

Suitable for securing premises such as shopfronts, whilst maintaining the see-through aspect when the shop is backlit. Used extensively in shopping malls and high street retail premises, perforated lath roller shutters present an economical method of providing a secure closure to large or small openings.
