Penguard Express CF
Verified by manufacturer 25 days ago
EPD
Certificate type
Two-component polyamide cured epoxy coating.
Application
Suitable for use with steel structures exposed up to very highly corrosive atmospheric environments including buildings, bridges, refineries, power plants, mining installations and other heavy industry structures.
Description
A two-component polyamide cured epoxy coating for use as a primer, mid-coat, finish coat, or as a single coat system in atmospheric environments.
It is a fast-drying, high solids, high build product designed for new construction where short dry to handle and over coating times are required.
Suitable for properly prepared aluminium, carbon steel, galvanized steel, shop primed steel, and stainless steel substrate, the product is tintable in a wide range of colours in Jotun's Multicolor Industry (MCI) system.
Features and benefits:
- Tintable in a wide range of colours.
- Colour stable.
- Fast dry-to-recoat and handling.
- Very low volatile organic compound (VOC).
- The product has been independently tested and is deemed to be compliant with the most stringent green building ratings systems like LEED or BREEAM.
General information
Color | Other Guidance for specification option: According to Multicolor Industry tinting system (MCI). |
Finish | Matt |
Material | Epoxy resin |
Shape | Formless |
Uniclass | |
CAWS | G10/630 Galvanizing plus site-applied G10/635 Thermally sprayed zinc coating plus site-applied G10/638 Shop priming G10/640 Shop painting G10/65 Shop priming for G10/650 Site painting G10/660 Shop plus site painting M60/12 Gloss paint M60/130 Gloss paint M60/175 Protective coating M61/110 On-site coating to primed steel M61/115 On-site coating to galvanized steel M61/120 On-site coating to existing steel M61/140 On-site overcoating to existing steel M61/150 Off-site coating to unprimed steel M61/160 Off-site coating to primed steel M61/170 Off-site coating to galvanized steel |
Product range |
Specification data - Solvent-based finishing coats
Composition | Two component, polyamide-cured epoxy coating. |
Sheen | Semi-gloss. |
Colour | Guidance for specification option: According to Multicolour Industry tinting system (MCI); consult manufacturer for details. |
Capacity | 20 L. |
Sustainability data
Material | Epoxy resin |
Third party certifications
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Third party certifications
EPD
NEPD-6731-6060
