Pedestrian Guard Railings
Verified by manufacturer 5 months ago
Hollow tubular rail galvanised pedestrian railings.
Application
Specifically designed for highway applications, providing an effective roadside barrier for pedestrians while allowing good visibility from a motorist's view point. For use on highways and schools.
Description
Hollow tubular rail fencing. Featuring a bolt-together design for easy installation or replacement, the solid pale construction and welded hollow tubular rail offer extreme strength and durability.
Features and benefits:
- Conforms to UK Highways Specifications.
- Strong welded construction to BS EN 7818 Class 1.
- Can be manufactured to suit gradients and radii.
- Galvanized to BS EN 1461 as standard or can be powder-coated to BS EN 13438 at extra cost.
- Standard, see-through or staggered designs.
- 25-year guarantee.
General information
Color | Other Black Green Grey Blue |
Finish | Galvanized Powder-coated |
Material | Steel |
Width | 1000 mm 1800 mm 2000 mm |
Height | 1100 mm |
Warranty description | 25 year |
Uniclass | |
CAWS | Q40/30 Proprietary fencing Q40/340 Steel vertical bar fencing Q40/430 Proprietary fencing |
Specification data - Metal post and panel barrier systems
Classification data | |
Posts | 1370 mm long, 50 x 30 mm. Guidance for specification option: Centres: To suit panel width. Height above ground: 1100 mm. |
Post foundations | Set in concrete. Base plated. Cranked. |
Rails | Welded hollow tubular rail. Guidance for specification option: Vertical and horizontal rails: 50 x 30 mm rectangular hollow section (RHS) and pales are 12 mm solid at 112 mm centres. |
Panels | Standard, 1100 x 1000 mm. Guidance for specification option: Inline pales from top to bottom. Standard, 1100 x 1800 mm. Guidance for specification option: Inline pales from top to bottom. Standard, 1100 x 2000 mm. Guidance for specification option: Inline pales from top to bottom. See-through, 1100 x 1000 mm. Guidance for specification option: Inline pales and clear visibility slot below top rail, providing increased vision for motorists. See-through, 1100 x 1800 mm. Guidance for specification option: Inline pales and clear visibility slot below top rail, providing increased vision for motorists. See-through, 1100 x 2000 mm. Guidance for specification option: Inline pales and clear visibility slot below top rail, providing increased vision for motorists. Staggered, 1100 x 1000 mm. Guidance for specification option: Infill bars are staggered. Staggered, 1100 x 1800 mm. Guidance for specification option: Infill bars are staggered. Staggered, 1100 x 2000 mm. Guidance for specification option: Infill bars are staggered. |
System accessories | None. Matching gates. Guidance for specification option: To be specified separately. |
Fence topping | Flat bar top. |
Worked finish | Galvanized. Guidance for specification option: Standard; hot-dip galvanized. Powder-coated, black RAL 9005. Powder-coated, green RAL 6005. Powder-coated, other. Guidance for specification option: Insert requirements. Marine coated. Guidance for specification option: For installations near the sea or an estuary. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Material | Steel |
Expected Life | 25 year |
