Pedestrian Barrier – Balustrade ASH1120.F
Verified by manufacturer 5 months ago
ASH1120.F.FW.COL.G
ASH1120.F.FW.COL.G
Floor to floor/ wall fixed robust flat bar aluminium barrier rail.
Application
- Aluminium doors.
- Timber doors.
- Glass doors.
- Commercial doors.
Description
A floor to floor/ wall fixed robust flat bar aluminium barrier rail.
These barrier rails come colour coated in any standard RAL or BS colour with a glazed infill to comply with BS 7036 or available with a metal infill.
They are also available in a mill finish for powder coating by others.
General information
Color | Manufacturer guidanceStandard RAL & BS colours available, other colours available on request |
Finish | Mill Powder-coated |
Material | Aluminium Glass |
Shape | Rectangle |
Length | Bespoke |
Width | 900 mm Bespoke |
Height | 900 mm Bespoke |
Warranty description | Two year |
Uniclass | |
CAWS | L30/560 Proprietary balustrades L30/55 Proprietary balustrades |
Specification data - Balustrade and guarding systems
Uprights | Aluminium, polyester powder-coated.Guidance for specification option: Standard RAL & BS colours available, other colours available on request. Consult manufacturer for options and insert requirements. Aluminium, mill finish. |
Infills | Glazing. |
Rails | |
Handrails | Aluminium handrails. |
Finish/ Colour | Mill. Polyester powder coated. Guidance for specification option: Standard RAL & BS colours available, other colours available on request. |
Dimensions | 900 x 900 mm. Guidance for specification option: As standard but can also be made to order to customer requirements. Bespoke. Manufacturer guidanceWidth x height. |
Fixing | Floor to wall. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Recyclability | Aluminium and stainless steel is recyclable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 95 % |
Literature
ASH1120.F Product Data Sheet
