Pedeck Liberty Porcelain - Raised Floor Platform

Verified by manufacturer 18 days ago

Square, 600 x 600 mm

Rubbertech Ltd Variant:

Tiles for the creation of raised floor platforms in the heavy load traffic areas and are suitable for both commercial and residential applications.

Jump to:
+44 (0)1824 702666 Website

Application

Suitable for heavy load traffic areas in both commercial and residential applications.

Some application areas can be:

  • Flat roof terrace.
  • Balconies.
  • Landscaping area.
  • Gardens.
  • Walkways.

Description

Liberty Tiles are lightweight, anti-slip, economical and aesthetically pleasing solution, requiring no sealing, they will not stain and will remain looking as good as the day they were installed. The tiles are comprised of a 20 mm single layer of load bearing porcelain stoneware, with excellent technical and aesthetic features.

They are recommended to be installed as part of the Strada PED System, they are long lasting and have structural inalterability in any climate conditions.

Features and benefits:

  • Fast and easy installation.
  • High load bearing.
  • Non-fixed and easily accessible.
  • Frost and fire proof.
  • Slip and stain resistant.
  • Available in a range of simulated stone finishes, giving the aesthetics of natural stone minus the expense, maintenance and upkeep.
  • Available in four colours and three sizes.
  • Compatible 8.5 mm indoor options are also available upon request.
  • Facilitate the maintenance of wiring and piping systems. For a proper water outflow Rubbertech Ltd suggest to lay with a 1% minimum slope.
  • Long cuts are completed with a wet saw, smaller cuts around objects are cut with angle grinders with a diamond blade.

General information

Color

Beige

Ivory

White

Grey

Finish

Anti-slip

Smooth

Semi-gloss

Material

Porcelain

Shape

Square

Length

600 mm

1200 mm

Width

600 mm

900 mm

Height

20 mm

Warranty description

Two year

Uniclass

Pr_25_93_60_10 Clay paving tilesPrimary

CAWS

Q25/50 Natural stone slabs

Q25/310 Natural stone slabs

SKU Code

LibertyPorcelain

Specification data - Clay paving tiles

Classification data

Supplied by

Rubbertech Ltd.

Tile material

Ceramic.

Colour

White.
Beige.
Light grey.
Dark grey.

Finish

Plain.

Plan shape

Square.

Size (minimum)

600 x 600 mm.

Thickness (minimum)

20 mm.

Chemical resistance

GA UNI EN ISO 10545.13; 5 UNI EN ISO 10545.14.

Bending strength

-50 N/mm².

Breaking load

To EN 12825, Class 1, 8.28 kN.

Mechanical strength

To EN 1339, U11.

Frost resistance

To ISO 10545.12.

Water absorption

To ISO 10545.3, -0.1%.

Slip resistance

R12 (dry).

Manufacturer guidance

Slip resistance - DIN 51130, DIN 51097, ASTM C1028, BCRA.

Sustainability data

Contains Red List materials

No

Country of material origin

Italy

Country of product manufacture

Italy

Manufacturing plant location

Material

Porcelain

Recyclability

100% recyclable

Expected Life

35 year
