Aluminium finish
ISO 45001 Health and Safety Management
Certificate type
ISO 9001 Quality Management
Certificate type
Create elegant, infinity-edge ceilings with dramatic transitions in height, sharp lighting channels, and a wafer-thin finish. Unique, patented design prevents mid-ceiling cracks and discolouration.
Knife edge trim for elegant, slim line acoustic plaster and plaster ceiling edges. Installed as part of a drylining package.
The Oscar Evo-Blade is a contemporary alternative to the traditional ceiling upstand, elegantly presenting the illusion of an infinity-edge ceiling, while allowing for feature lighting designs. The Oscar Evo-Blade stylishly disguises bulky ceiling buildups, making them appear elegant and wafer-thin.
The knife-edge trim with a patented design for use with standard plaster, jointing filler, Oscar Acoustics' acoustic sprays and plasters (see SonaSpray range and Oscar Elite) and lighting system of your choice.
Features and benefits:
Color | Other Guidance for specification option: Can be powder coated any colour. Silver |
Finish | Smooth Guidance for specification option: Extruded aluminium. |
Material | Aluminium |
Shape | Other Guidance for specification option: Patented design. |
Length | 2000 mm |
Width | 173.5 mm |
Height | 58.3 mm |
Uniclass | |
CAWS | P20/30 Proprietary P20/170 Proprietary |
Product range |
Material | Aluminium. |
Finish as delivered | Smooth extruded aluminium. |
Colour | Silver. |
Profile | Angle. |
Size | 2000 x 173.5 x 58.3 mm. |
Accessory and special shape types | Packs of straight shims for lining up straight runs and right angle shims for corners. |
Net dry density | 2.066 kg/m. |
Contains Red List materials | No |
Country of material origin | Europe Manufacturer guidanceEU. |
Country of product manufacture | United Kingdom |
Material | Aluminium |
Recyclability | 100% Guidance for specification option: Fully recyclable as aluminium. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 41 % Guidance for specification option: 59% virgin material and 41% recycled material. The recycled materials is 100% post-industrial content. |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
