Application

Domestic and lightly-loaded commercial use; lateral restraint for vehicular and pedestrian pavements including footpaths, cycle tracks, driveways, adoptable highways, commercial pavements, roof top and balcony applications. Installation standard: BS 7533-6:1999.

Description

Designed to integrate with all Brett standard concrete paving ranges.

Available in two popular edging colours. The 200 mm length allows fewer units to be used to create borders and boundaries, saving installation time while offering excellent value for both DIY projects and professional installations.


Standards:

Brett Landscaping operate a number of independently audited management systems:

  • BS EN ISO 9001: 2008 Quality Management System.
  • BS EN ISO 14001: 2004 Environmental Management System.
  • OHSAS 18001: 2007 Health and Safety Management System.
  • BES 6001 Responsible Sourcing of Construction Products.

General information

Color

Red

Grey

Finish

Smooth

Material

Concrete

Guidance for specification option:

Precast (semi-dry-pressed and vibrated).

Shape

Rectangle

Length

200 mm

Width

100 mm

Height

60 mm

80 mm

Uniclass

Pr_25_93_45_18 Concrete kerbsPrimary

CAWS

Q10/10 Precast concrete

Q10/110 Proprietary precast concrete

Specification data - Concrete kerbs

Standard

To BS EN 1338: 2004.

Physical properties

-

Colour

Brindle.

Charcoal.

Finish

Smooth.

Profile

-

Designation

SP.

Dimensions

200 x 100 x 60 mm.

200 x 100 x 80 mm.

Weathering resistance

Class 3.

Abrasion resistance

Class 3.

Guidance for specification option:

≤23 mm; determined by Wide Wheel Abrasion test.

Bending strength

Manufacturer's standard.

Guidance for specification option:

Characteristic tensile splitting strength ≥3.6 MPa; Failing load ≥250 N/mm.

Unpolished Slip Resistance Value (USRV) (minimum)

≥55; Potential for slip: Low.

Recycled content (minimum)

Guidance for specification option:

Manufacturer's standard.

Third-party certification

CE marked.

ThermalConductivity

1.2 W/m·K.

Literature

Omega Kerb TDS Sept 21

Omega Kerb TDS Sept 21
