Ogee System
Application

Suitable for application on terrace houses, semi-detached houses and smaller office and commercial buildings.

Description

A traditional, recyclable ogee gutter.


Features and benefits:

  • The rainwater accessories are injection moulded using virgin PVC. These components incorporate a simple clip together system for fitting gutter and pipe profiles. The gutter clips include pre-installed seals that are lubricated during manufacture to ease the clipping process.
  • Designed for use with 68 mm diameter, or 65 mm square pipework.
  • Kitemark 508760.
  • Low maintenance.
  • Durable and tough.
  • Head of water (maximum): 68 mm.
  • Short length of gutter: 3400 mm.

General information
Color

Available in five colours.

Features

Durable and tough.

Swish gutters and pipes are two-tone in appearance. The core recycled material is grey and has been left this colour in order to avoid the unnecessary use of additional colouring agent

The outer skin is virgin material that is co-extruded onto the surface of the core to enhance the finished appearance and to aid colour matching

The rainwater accessories are injection moulded using virgin PVC. These components incorporate a simple clip together system for fitting gutter and pipe profiles. The gutter clips include pre-installed seals that are lubricated during manufacture to ease the clipping process

Designed for use with 68 mm diameter, or 65 mm square pipework

Finish

Gloss.

Material

PVC which contains no cadmium or lead.

Size

Width: 120 mm; Depth: 80 mm (front); 70 mm (back).

WarrantyDescription

Ten-years.

Excludes- Caramel.

Uniclass 2015
Pr_65_50_35_92 Unplasticized polyvinyl chloride (PVC-U) eaves guttersPrimary
CAWS

R10/16 PVC-U gutters

R10/350 PVC-U gutters

Specification data - Unplasticized polyvinyl chloride (PVC-U) eaves gutters Enhanced data
Standards

BS EN 607:2004.

Profile

Ogee.

Size (nominal)

Width: 120 mm; Depth: 80 mm (front), 70 mm (back).

Colour

White

Black

Brown

Caramel

Anthracite Grey

Integral accessories

OGO2 Stopend Outlet, right hand

OGO3 Stopend Outlet, left hand

OGA1 90° Internal Angle

OGA2 90° External Angle

OGA3135° Internal Angle

OGA4 135° External Angle

OGA5 150° External Angle

OGE1 External Stop-end

OGE1 External Stop-end, left hand

OGE2 External Stop-end, right hand

OGO1 Running Outlet

Bracket

OGK1 Fascia Bracket

OGU1 Union Bracket

OGK2 Top Hung Fascia Bracket

Product Reference

Ogee System

Environmental information
Contains Red List materials

Yes

Country of material origin

United Kingdom

Recyclability

100% recyclable.
