Nylofor 2D Super + Twilfix - Metal mesh fence panel
Application

Suitable for use where both high rigidity and security are needed.

Description

Nylofor® 2D Super is a complete system with 2.5 metre panels, providing both high rigidity and security.


Features and benefits:

  • Very high rigidity achieved by using horizontal wires.
  • Nylofor® 2D super has similar characteristics and properties to Nylofor® 2D, but features twin 8 mm diameter horizontals for maximum ridgidity.
  • Complies with BS 1722-14, category 1 and 2.

General information

Color

Green

RAL 6005 (Moss green).

Grey

RAL 7016 (Anthracite grey).

White

RAL 9010 (Pure white).

Black

RAL 9005 (Jet black).

Finish

Galvanized

Polyester powder coated

Material

Metal

Size

WarrantyDescription

Ten years

Standard 10 years guarantee.


Uniclass 2015

Ss_25_14_67_51 Metal mesh panel fencing systemsPrimary

CAWS

Q40/126 Open mesh steel panel security fencing

Q40/27 Open mesh steel panel fencing

Specification data - Metal mesh panel fencing systems Enhanced data

Standard

To BS 1722-14.

Category

1 and 2.

Posts

Steel posts.

Rails

Steel fencing and barrier rails.

Panels

Steel welded mesh panels.

Mesh pattern: 200 x 50 mm. Horizontal wires: Heavy gauge flat Weldmesh panels have a open mesh profile with a decorate appearance and robust construction. The principle feature is twin 8 mm diameter rods positioned on either side of the verticals. Vertical wires: 2DS: 6 mm diameter.

Fence topping

Barbed on top.

System accessories

None.

Single swing gates.

Double swing gates.

R2000. - Cantilever sliding gates.

R2800. - Cantilever sliding gates.

Sliding gates on rail.

Quick Folding Gate Faldivia.

Fixing brackets.

U channel clamp bar.

Product Reference

Nylofor 2D Super + Twilfix - Metal mesh fence panel

Panel size

600 x 2500 mm.

800 x 2500 mm.

1000 x 2500 mm.

1200 x 2500 mm.

1400 x 2500 mm.

Show more

Size

60 x 60 x 2.0 mm.

Sentinel twilfix 2000 RHS.

80 x 60 x 2.5 mm.

Multi-lift fences up to 4000 mm.

Colour

Green.

Grey.

White.

Black.

Other.

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2017 2 2.1
IFC
- 2 2.1
Download now from NBS National BIM Library
