Newton 902-P
Application

Priming of damp, non-porous concrete and screed to provide a DPM and vapour barrier, prior to the application of moisture sensitive flooring, coatings, membranes, levelling compounds and screed. Areas of application include:

  • Podium decks.
  • Car parks.
  • Warehousing and storage.
  • Garages.
  • Plant rooms.

Description

Two-part, solvent free, damp tolerable, coloured, epoxy based primer which is applied to non-porous surfaces as a barrier to residual substrate moisture and vapour within concrete and screeds. For porous substrates, Newton 901-P should be applied first to seal the surface and remove the porosity.

The high quality, low viscosity epoxy formulation allows for application onto damp surfaces, allowing for the speedy application of flooring, coatings, membranes, levelling compounds and screeds to damp substrates. Newton 902-P is quick and simple to use and can be applied over cementitious screeds and concrete just seven days after placement. It is applied by brush or roller in two different coloured, gloss coats, or one coat if applied above Newton 901-P - consult manufacturer for details.

Features and benefits:

  • Damp-tolerable.
  • Can be applied to concrete and screed seven days after placement.
  • Solvent free.
  • Provides a good vapour barrier.
  • High-bond damp proof membrane (DPM) that provides a barrier to vapour and to prevent osmotic blistering.
  • Life expectancy is equal to that of the surface it is applied to.

Applications:

Priming of damp, non-porous concrete and screed to provide a DPM and vapour barrier, prior to the application of moisture sensitive flooring, coatings, membranes, levelling compounds and screed. Areas of application include:

  • Podium decks.
  • Car parks.
  • Warehousing and storage.
  • Garages.
  • Plant rooms.

- Suitable substrates:

Indoor or outdoor floors of correctly formed, compacted and prepared:

  • Concrete of at least seven days old.
  • Screed of at least seven days old.

General information
Uniclass 2015
Pr_35_31_66_67 Primer-sealersPrimary
CAWS

C42/310 Repair mortar

J10/110 Proprietary mortar

J30/110 Cold applied tanking . . . . . .

J31/110 Cold deck roof coating

J31/120 Warm deck roof coating

J31/130 Inverted roof coating

J31/353 Waterproof coating

J40/290 High density polyethylene/ polypropylene studded cavity drain membrane

J40/295 Geocomposite studded cavity drainage/ venting membrane

J40/47 High density polyethylene/ polypropylene studded cavity drain membrane

Specification data - Primer-sealers
Product Reference

Newton 902-P

Colour

Green (RAL 6010)

Yellow (RAL 1005)

Standard product features

Form (two component):

Low viscosity epoxy resin.

Weight:

5.2 kg.

Technical characteristics:

- General:

  • Specific gravity: 1.11.
  • Application temperature: 8–30°C.
  • Service temperature: -15 to +50°C.
  • Application rate: First coat: 0.35 kg/m². Second coat: 0.20 kg/m².
  • Odour: Ammonia smell when mixing.
  • Volatile organic compounds (VOC) content: 0%.

- Drying:

  • Inter-coat adhesion window: At 8°C: 24–48 h; at 10°C: 24–48 h; at 15°C: 18–30 h; at 20°C: 12–24 h; at 25°C: 10–24 h.
  • To be kept free of rain: At 8°C: 24 h; at 10°C: 24 h; at 15°C: 18 h; at 20°C: 12 h; at 25°C: 10 h.
  • Ready for temporary foot traffic: At 8°C: After 70 h; at 10°C: After 60 h; at 15°C: After 48 h; at 20°C: After 36 h; at 25°C: After 24 h.

- Cured membrane:

  • Membrane thickness: First coat: 0.30 mm. Second coat: 0.18 mm.
  • Adhesion to concrete to BS EN 13892-8 (>B2.0): 3.5 MPa.
  • Water vapour transmission rate to EN 1504-2– UK Perm: >1.0 g/m²/24 hrs.
  • Water vapour diffusion resistance – Sd value: 2.066 m.
  • Water vapour diffusion resistance – μ value: 11 478 μ.
  • Water vapour diffusion resistance: 10.331 MNs/g.
  • Reaction to fire classification: Euroclass F.

Product Options

Colour:

RAL Colour is based on the paste and is not the exact finished colour. Other colours are available on request but will be subject to lead time and minimum order quantity - consult manufacturer for further details.
