NBS Source
Newton 806 CWC


Cold internal surfaces affected by condensation and subject to the formation of black mould such as:

  • Solid walls;
  • Pantries and larders;
  • Bathrooms and shower rooms;
  • Kitchens;
  • Ceilings;
  • Elevations exposed to cold winds.


A white thermal coating for use on cold and poorly insulated surfaces. It contains specific mineral powders which, due to their insulating features, warm the surface of the treated wall.

Condensation is formed when warm air, holding water vapour, comes into contact with a cold surface (dew point surface). The air near to the cold surface cools and the cooler air is unable to hold as much water vapour as it was able to when it was warmer. The water vapour that the cooler air is unable to hold is deposited on the adjacent cool surface. The 5°C difference between a surface treated with CWC and one not treated with CWC will, in most cases, take the wall surface temperature to above the dew-point, meaning that the formation of condensation and mould is eliminated. the dew-point, meaning that the formation of condensation and mould is eliminated.

Features and benefits:

  • DIY solution.
  • Very cost effective.
  • Quick and easy to apply.
  • Effective and hygienic solution to black mould.
  • Can be over-painted with water based emulsions or tinted with standard paint tints.
  • Solvent free, non-toxic and odourless.
  • Non-flammable - No VOCs.
  • Suitable substrates include existing painted surfaces, skimmed plasterboard, clean mortar walls , non-ferrous metal, render, plaster and finishing plaster, timber, glass, medium density fibreboard (MDF), wallpaper, timber panelling, and plywood.
  • Has a life expectancy of ten years.
  • Can be applied via paint brush, roller, or paint spraying machine.

General information




Thermal paint


Liquid form

Uniclass 2015

Pr_35_31_68_97 Water repellentsPrimary


J30/10 Cold applied damp proofing

J30/110 Cold applied tanking . . . . . .

J30/130 Cold applied damp proofing . . . . . .

M60/175 Protective coating

M60/18 Special coating

M60/195 Special coating

Product range

Damp Proofing Systems

Specification data - Water repellents Enhanced data


White thermal coating liquid which contains specific mineral powders.

Product Reference

Newton 806 CWC (CWC)

Application rate

0.5–0.7 L/m.

Application temperature

+5°C to +35°C.

Service temperature

-15°C to +40°C.

Packaging - Plastic bucket

5 L.

Shelf life

12 months.

Ready for next coat (20°C; Relative Humidity (RH) 40%)

6 hours.

Fully cured (20°C; Relative Humidity (RH) 40%)

6 hours.

Vapour permeability μ)

Highly breathable.


Newton 806 CWC

Newton 806 CWC
