NBS Source
Newton 106 FlexProof

Application

Suitable for use where waterproofing is required within movement joints and at the interfaces of differing materials.

Suitable substrates include:

  • Concrete of at least 20 kN;
  • Concrete block walls with flush pointing;
  • Screed;
  • Metal;
  • Plastics;
  • Timber;
  • Glass.

Description

A highly advanced single component liquid waterproofing material for the waterproofing of joints, which forms an elastomeric polymer membrane that is rainproof in minutes and capable of handling severe building movements and deformations.

The product provides a good bond to most building materials and with very high levels of flexibility, and is capable of resisting both negative side and positive side water-pressure at construction joints, even where movement is expected.

Newton 106 FlexProof has the ability to remain watertight against positive pressure, even when resisting 20% expansion and compression and 10% shear.


Surface preparation is required, as is protection after application - consult manufacturer for details.


Features and benefits:

  • Single component and ready to use, and therefore no mixing is required.
  • No primer required - saving on primer and labour costs.
  • Single coat application.
  • 100% waterproof, but allows vapour diffusion.
  • Very flexible - Resistant to movement and fissures in substrates.
  • Resistant to both positive and negative side water pressure.
  • Weather-tight skin forms within a few minutes of application.
  • Excellent adhesion to suitable substrates.
  • Resistant to temperature variations maintaining its characteristics between -40 and +90°C.
  • Excellent resistance to the high alkalinity of concrete.
  • Where the product is exposed to UV and weathering, the life expectancy should be at least ten years.
  • Can be applied using a metal trowel, metal putty knife, brush for detailing, pouring directly from the bag (NV only) or cartridge gun (X1 only) - consult manufacturer for further details.


Curing:

  • To be kept rain-free (light rain): At 5°C: For 15 minutes; at 10°C: For 12 minutes; at 15°C: For 10 minutes; at 20°C: For 10 minutes; at 25°C: For 5 minutes.
  • To be kept rain-free (heavy rain): At 5°C: For 20 minutes; at 10°C: For 17 minutes; at 15°C: For 15 minutes; at 20°C: For 15 minutes; at 25°C: For 10 minutes.
  • Ready for protection boards: At 5°C: After 30 minutes; at 10°C: After 27 minutes; at 15°C: After 25 minutes; at 20°C: After 25 minutes; at 25°C: After 20 minutes.
  • Fully cured: At 5°C: After 5 days; at 10°C: After 4 days; at 15°C: 4 days; at 20°C: 3 days; at 25°C: 3 days.

General information

Finish

Smooth, glossy grey surface.

Color

Grey

Material

Flexible polymer

Shape

Paste form.

Size

Medium viscosity version (X1) available in 290 ml or 15 kg containers. Low viscosity version (NV) available in 7.5 kg containers.

WarrantyDescription

When fully covered and protected Newton 106 FlexProof will provide, under normal conditions, a durable waterproof coating for the life of the building to which it is installed.

Uniclass 2015

Pr_25_57_51_66 Polymeric membranesPrimary

CAWS

J30/130 Cold applied damp proofing . . . . . .

J30/10 Cold applied damp proofing

Product range

Liquid Waterproofing Membranes

Specification data - Polymeric membranes Enhanced data

Standard

To EOTA TR-003, BS EN 13813: 2002, DIN EN 1928, DIN EN 12311-2, EN ISO 11431:2002 and DIN EN 13501-1.

Width (minimum)

As required.

Colour

Grey.

Product Reference

Newton 106 FlexProof NV

Low viscosity, pourable material that is more suited to application to horizontal surfaces and movement joints.

Newton 106 FlexProof X1

Medium viscosity, thixotropic paste that is suitable for application to vertical surfaces and within vertical joints.

Density / Specific gravity

1.54 (X1) and 1.44 (NV).

Application rate - over joints

3.85 kg/m² (X1).

Application rate - not to joints

3 kg/m².

Application rate - movement joints

Depth of 50% of the joint width.

Minimum application temperature - substrate

+1°C and rising.

Maximum application temperature - air

+35°C.

Service temperature

-40°C to +90°C.

Odour

Slight polymer.

VOC content

None.

Adhesion to concrete

> 450 KPa EOTA TR-003.

TensileStrength

1.25 N/mm² (X1) and 1.60 N/mm² (NV). BS EN 13813:2002.

Elasticity when breaking - 2 mm film

250% (X1) and 450% (NV). DIN EN 12311-2.

Resistance to dilute acid/alkaline

Excellent. DIN EN 1928.

Shore hardness - A

40.

UV resistance

Ten years. EN ISO 11431:2002.

Reaction to fire classification - Euroclass

E. DIN EN 13501-1.

Digital objects

Platform Compatible Version Certified to
IFC

IFC2X3

2

1.3
Revit

Revit 2016

5

2.0
Download now from NBS National BIM Library

Literature

Newton 106 Highly advanced single component liquid waterproofing

Newton 106 Highly advanced single component liquid waterproofing
